The ATmel MCU ATMEGA 2560 R3 SMD Board Improved Version CH340G Board is a micro-controller board base on the ATmega2560. It has a USB host interface to connect with Android based phones, base on the MAX3421e IC.
It has 54 digital input/output pins (of which 15 can be used as PWM outputs); 16 analog inputs, 4 UARTs (hardware serial ports), a 16 MHz crystal oscillator; a USB connection, a power jack, an ICSP header, and a reset button. The MEGA ADK is base on the Mega 2560. Similar to the Mega 2560 and Uno, it features an ATmega8U2 program as a USB-to-serial converter. Revision 3 of the Mega ADK board has a resistor pulling the 8U2 HWB line to ground, making it easier to put into DFU(Device Firmware Upgrade) mode.
The Mega Arduino R3 Android Accessory Development Kit (ADK) can be powered via a USB connection or with an external power supply. The power source is selected automatically. External (non-USB) power can come either from an AC-to-DC adapter (wall-wart) or battery. The adapter can be connected by plugging a 2.1mm centre-positive plug into the board’s power jack.
Leads from a battery can be inserted in the GND and Vin pin headers of the POWER connector. Because the Mega R3 Android Accessory Development Kit (ADK) is a USB Host, the phone will attempt to draw power from it when it needs to charge. When the ADK is powered over USB, 500mA total is available for the phone and board.
Embark on a journey of innovation with the ATMEGA 2560 R3 SMD Board Improved Version, designed to empower creators, engineers, and hobbyists alike. This cutting-edge microcontroller board represents the pinnacle of technology, featuring enhanced functionalities and unparalleled performance. Whether you’re a seasoned professional or an aspiring enthusiast, this board is your gateway to realizing your boldest ideas.
Key Features of ATMEGA 2560 R3 SMD Board Improved Version:
- Enhanced Performance: The ATMEGA 2560 R3 SMD Board Improved Version boasts superior processing power, enabling faster execution of tasks and seamless multitasking capabilities. With its upgraded performance, you can tackle even the most demanding projects with ease.
- Advanced Connectivity: Connect with ease thanks to the board’s comprehensive range of connectivity options, including USB, UART, SPI, and I2C interfaces. Whether you’re interfacing with sensors, displays, or other peripherals, this board ensures seamless communication for uninterrupted operation.
- Expanded Memory: Say goodbye to memory constraints with the ATMEGA 2560 R3 SMD Board’s expanded memory capacity. With ample storage space for your programs, data, and variables, you can unleash your creativity without limitations.
- Versatile I/O Ports: Flexibility is key, and this board delivers with its array of versatile I/O ports. From digital and analog inputs to PWM outputs, you have the flexibility to interface with a wide range of components and peripherals, empowering you to bring your ideas to life.
- Robust Design: Built to withstand the rigors of prototyping and experimentation, the ATMEGA 2560 R3 SMD Board features a robust design that ensures reliability and longevity. Whether you’re working in a professional lab or a home workshop, you can trust this board to deliver consistent performance day in and day out.
Applications of ATMEGA 2560 R3 SMD Board Improved Version :
- Embedded Systems Development: From robotics and automation to IoT (Internet of Things) applications, the ATMEGA 2560 R3 SMD Board is the perfect platform for developing cutting-edge embedded systems. Its advanced features and expansive capabilities make it ideal for tackling complex projects in various domains.
- Prototyping and Testing: Rapid prototyping is essential for bringing ideas to fruition, and this board streamlines the prototyping process with its versatile functionality and ease of use. Whether you’re testing new concepts or refining existing designs, the ATMEGA 2560 R3 SMD Board provides the tools you need to iterate quickly and efficiently.
- Educational Purposes: The ATMEGA 2560 R3 SMD Board serves as an invaluable educational tool for students and educators alike. With its user-friendly interface and extensive documentation, it facilitates hands-on learning experiences in electronics, programming, and microcontroller applications, empowering the next generation of innovators.
- DIY Projects and Hobbyist Endeavors: Let your imagination run wild with DIY projects and hobbyist endeavors powered by the ATMEGA 2560 R3 SMD Board. Whether you’re building custom gadgets, interactive art installations, or home automation systems, this board provides the foundation for endless creativity and exploration.
- Industrial Automation: In industrial settings, reliability and performance are paramount, and the ATMEGA 2560 R3 SMD Board delivers on both fronts. With its robust design and advanced features, it’s well-suited for applications ranging from control systems and monitoring devices to data logging and instrumentation.
Package Includes :
1 x Mega R3 Android Accessory Development Kit.
FAQ
1. who will use this ATMEGA 2560 R3 SMD Board Improved Version?
Engineers, hobbyists, students, educators, and professionals in various fields utilize the ATMEGA 2560 R3 SMD Board Improved Version for microcontroller-based projects and applications.
2. what is the use of this ATMEGA 2560 R3 SMD Board Improved Version?
The ATMEGA 2560 R3 SMD Board Improved Version is utilized for developing embedded systems, prototyping, education, DIY projects, and industrial automation applications.
3. Where can we buy this ATMEGA 2560 R3 SMD Board Improved Version?
This product is available online at https://aiiottech.in/product/atmega-2560-r3-smd-board-improved-version/and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103
4. When can I get this ATMEGA 2560 R3 SMD Board Improved Version after placing the order?
RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 2-3 working days.
5. How this ATMEGA 2560 R3 SMD Board Improved Version is better than other similar products?Â
The ATMEGA 2560 R3 SMD Board Improved Version surpasses competitors with enhanced performance, expanded memory, comprehensive connectivity, robust design, and versatile applications.
