CD4030 Quad 2-Input Exclusive OR (EXOR) Gate IC (DIP-14 Package)

CD4030 Quad 2-Input Exclusive OR (EXOR) Gate IC is a versatile CMOS logic integrated circuit designed for digital systems requiring logical comparison, arithmetic operations, and signal processing. Featuring four independent EXOR gates, this IC delivers dependable performance with low power consumption, wide operating voltage range, and excellent noise immunity.

Manufactured using CMOS technology, the CD4030 is well-suited for both commercial and industrial electronic applications. It is commonly used in digital computation, parity checking, signal encoding/decoding, frequency detection, and data comparison circuits. With its standard pin configuration and high reliability, the CD4030 remains a preferred choice for engineers, educators, hobbyists, and electronics manufacturers.

Key Features of CD4030 EXOR Gate IC

• Quad 2-Input EXOR Gates
  Contains four independent Exclusive OR gates in a single package, enabling efficient circuit design.

• Wide Operating Voltage Range
  Operates from 3V to 18V, making it compatible with both low-voltage and high-voltage CMOS systems.

• Low Power Consumption
  CMOS design ensures extremely low static power dissipation, ideal for battery-powered devices.

• High Noise Immunity
  Offers excellent resistance to electrical noise, ensuring stable logic operation.

• High Input Impedance
  Minimizes loading effects on preceding stages in digital circuits.

• TTL Compatibility
  Can interface with TTL logic levels when operated at appropriate supply voltages.

• Standard DIP Package
  Available in a 14-pin DIP package, suitable for breadboarding, prototyping, and PCB mounting.

Technical Specifications – CD4030 IC

• IC Type: Quad 2-Input Exclusive OR (EXOR) Gate

• Logic Family: CMOS

• Model Number: CD4030 / CD4030B

• Number of Gates: 4

• Inputs per Gate: 2

• Supply Voltage (VDD): 3V to 18V

• Logic Levels: CMOS compatible

• Propagation Delay: Typically 60–200 ns (depending on supply voltage)

• Input Capacitance: Low (typically 5 pF)

• Operating Temperature Range: –55°C to +125°C

• Package Type: 14-pin DIP / SOIC (variant dependent)

• Power Dissipation: Very low static dissipation

• Pin Configuration: Industry standard

Note: Electrical characteristics may vary slightly depending on manufacturer and package type.

Applications of CD4030 Quad EXOR Gate IC

The CD4030 IC is widely used across multiple digital and mixed-signal applications due to its flexibility and reliability.

Digital Logic & Computation

• Binary addition and subtraction circuits

• Half-adder and full-adder implementations

• Logical comparison and data evaluation

Data Processing & Communication

• Parity generator and parity checker circuits

• Data encoding and decoding systems

• Error detection logic

Signal Processing

• Phase and frequency detection

• Pulse shaping and signal conditioning

• Modulation and demodulation circuits

Control & Automation

• State detection and control logic

• Decision-making circuits in embedded systems

Education & Prototyping

• Digital electronics laboratory experiments

• Logic gate demonstrations and training kits

• DIY electronics and learning projects

Why Choose the CD4030 Quad EXOR Gate IC?

The CD4030 Exclusive OR Gate IC offers an excellent balance of performance, power efficiency, and design flexibility. Its ability to operate across a wide voltage range makes it suitable for diverse applications, from simple logic circuits to complex digital systems. The low power consumption and high noise immunity ensure reliable operation even in electrically noisy environments.

With four EXOR gates integrated into a single package, the CD4030 reduces component count, saves PCB space, and simplifies circuit design. Its compatibility with standard CMOS logic and ease of use make it a dependable choice for professionals, students, and hobbyists alike.

Buy CD4030 Quad 2-Input EXOR Gate IC Online

Upgrade your digital logic designs with the CD4030 Quad 2-Input Exclusive OR (EXOR) Gate IC. Ideal for computation, signal comparison, and digital control, this IC delivers reliable logic performance and long-term durability for a wide range of electronic applications.

Order now to experience efficient CMOS logic design with the trusted CD4030 IC.

Package Includes:

1 x CD4030 Quad 2-Input Exclusive OR (EXOR) Gate IC (DIP-14 Package)
