CD4053 Triple 2-channel Mux/Demux IC (DIP-16 Package)

CD4053 Triple 2-channel Mux/Demux IC is a highly reliable and versatile CMOS integrated circuit designed for efficient signal routing and switching in both analog and digital applications. Featuring three independent SPDT (Single Pole Double Throw) analog switches, the CD4053 allows seamless selection between multiple signal paths using simple logic control inputs.

Built using CMOS technology, the CD4053 IC offers low power consumption, wide operating voltage range, and high noise immunity, making it ideal for battery-powered devices, industrial electronics, communication systems, and embedded designs. Its ability to handle both analog and digital signals makes it a popular choice among engineers, students, and hobbyists.

With its compact DIP/SOIC package options and robust electrical characteristics, the CD4053 multiplexer/demultiplexer IC ensures reliable performance in demanding environments while maintaining design flexibility and ease of integration.

Key Features of CD4053 Mux/Demux IC

• Triple 2-Channel Analog Multiplexer/Demultiplexer
  Contains three independent SPDT switches, allowing simultaneous control of three separate signal paths.

• Analog and Digital Signal Compatibility
  Capable of switching both analog and digital signals with minimal distortion.

• Wide Operating Voltage Range
  Operates from 3 V to 18 V, suitable for both low-voltage and standard logic systems.

• Low Power CMOS Design
  Ensures minimal static power consumption, ideal for portable and battery-operated devices.

• High Noise Immunity
  CMOS architecture provides strong resistance to electrical noise and signal interference.

• Fast Switching Speed
  Enables rapid signal selection, making it suitable for audio, data acquisition, and communication applications.

• Break-Before-Make Switching
  Prevents short circuits during switching, ensuring safe and reliable operation.

• Compact & Easy-to-Use Package
  Available in standard DIP-16 and surface-mount packages for flexible PCB design.

Technical Specifications – CD4053 IC

• IC Type: Triple 2-Channel Analog Multiplexer/Demultiplexer

• Model: CD4053

• Switch Configuration: 3 × SPDT

• Operating Voltage (VDD): 3 V to 18 V

• Control Logic Level: CMOS compatible

• ON Resistance (RON): Typically 125 Ω at 15 V

• Signal Voltage Range: 0 V to VDD

• Switching Time: Typically < 100 ns (voltage dependent)

• Power Consumption: Very low (static CMOS)

• Operating Temperature Range: –55°C to +125°C

• Package Types: DIP-16, SOIC-16 (varies by manufacturer)

• Pin Count: 16 pins

Note: Electrical characteristics may vary slightly depending on manufacturer and operating conditions.

Applications of CD4053 Triple Mux/Demux IC

The CD4053 IC is widely used in a variety of electronic systems due to its flexibility and reliable performance. Typical applications include:

• Signal Routing & Switching Circuits
  Used for selecting between multiple input or output signals in analog and digital systems.

• Audio Signal Switching
  Commonly used in audio mixers, amplifiers, and sound processing circuits for clean signal selection.

• Data Acquisition Systems
  Enables multiplexing of sensor outputs into a single ADC input.

• Communication Equipment
  Used in RF and baseband signal routing, modulation, and channel selection.

• Embedded Systems & Microcontroller Projects
  Controlled by microcontrollers to expand input/output signal selection capabilities.

• Instrumentation & Measurement Devices
  Applied in oscilloscopes, multimeters, and test equipment for signal selection.

• Battery-Powered & Portable Devices
  Ideal for low-power electronics requiring efficient signal management.

• Educational & DIY Electronics Projects
  Popular among students and hobbyists for learning multiplexing and switching concepts.

Why Choose the CD4053 Multiplexer/Demultiplexer IC?

The CD4053 Triple 2-Channel Mux/Demux IC stands out for its wide voltage compatibility, low power consumption, and ability to handle both analog and digital signals. Its three independent switching channels provide enhanced design flexibility while reducing component count and PCB space.

Whether you are designing professional electronic equipment, developing embedded systems, or working on educational projects, the CD4053 IC offers stable performance, ease of integration, and cost-effective signal switching.

Upgrade your circuit design with the CD4053 Triple 2-Channel Multiplexer/Demultiplexer IC and achieve efficient, reliable, and flexible signal control.

Package Includes:

1 x CD4053 Triple 2-channel Mux/Demux IC (DIP-16 Package)

FAQ

1. Where can we buy this CD4053 Triple 2-channel Mux/Demux IC?

This product is available online https://aiiottech.in/product/cd4053-triple-2-channel-mux-demux-ic/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this CD4053 Triple 2-channel Mux/Demux IC after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: CD4053 Analog MUX-DEMUX Function Explained & Practical Testing
