CD4060 14Stage Ripple Carry Binary Counter IC (DIP-16 Package)

CD4060 14Stage Ripple Carry Binary Counter IC is a versatile CMOS logic integrated circuit that combines an on-chip oscillator with a 14-stage ripple carry binary counter. Designed for low-power and high-noise-immunity applications, the CD4060 is widely used in timing circuits, frequency division, clock generation, delay timers, and digital control systems.

This IC offers exceptional flexibility by allowing users to configure an external RC network or crystal oscillator to generate precise clock signals. The internal counter divides the input frequency into multiple outputs, making it an ideal solution for time-base generation and digital timing control. With its wide operating voltage range and low power consumption, the CD4060 is well suited for battery-powered and industrial electronics applications.

Packaged in a standard DIP-16 or SOIC-16, the CD4060 IC is easy to integrate into both prototyping and production-level designs.

Key Features of CD4060 IC

• 14-Stage Ripple Carry Binary Counter
  Provides multiple frequency-divided outputs from a single clock source.

• Built-In Oscillator Circuit
  Supports RC, ceramic resonator, or crystal oscillator configurations.

• Wide Operating Voltage Range
  Operates reliably from 3V to 15V, ensuring compatibility with various logic levels.

• Low Power Consumption (CMOS Technology)
  Ideal for energy-efficient and battery-powered devices.

• High Noise Immunity
  CMOS design ensures stable operation in electrically noisy environments.

• Reset Control Input
  Allows easy counter reset and timing control.

• Compact & Industry-Standard Package
  Available in DIP-16 and SMD packages for flexible PCB design.

Technical Specifications – CD4060 14-Stage Binary Counter

• IC Type: CMOS Ripple Carry Binary Counter with Oscillator

• Model: CD4060

• Counter Stages: 14

• Operating Voltage (VDD): 3V to 15V

• Input Frequency Range: Depends on external RC or crystal network

• Oscillator Type: External RC or crystal controlled

• Reset Input: Active HIGH

• Logic Family: CMOS

• Propagation Delay: Low (CMOS dependent)

• Output Configuration: Q4 to Q14 available

• Package Types: DIP-16 / SOIC-16

• Operating Temperature Range: –40°C to +85°C

• Power Consumption: Very low static power dissipation

Note: Electrical characteristics may vary slightly depending on the manufacturer.

Applications of CD4060 IC

The CD4060 14-Stage Ripple Carry Binary Counter IC is widely used in both commercial and educational electronics projects due to its flexibility and reliability. Common applications include:

• Digital Timers & Delay Circuits
  Used in time-delay switches, power-on reset circuits, and programmable timers.

• Frequency Dividers
  Converts high-frequency clock signals into lower frequencies for digital systems.

• Clock Generation Circuits
  Provides stable clock signals for microcontrollers and digital logic circuits.

• Real-Time Clock & Time-Base Circuits
  Suitable for generating timing pulses in clocks and counters.

• Industrial Control Systems
  Used in sequencing, control timing, and automation equipment.

• Consumer Electronics
  Found in appliances, alarm systems, and lighting control units.

• Educational & DIY Electronics Projects
  Popular for teaching digital electronics, counters, and timing concepts.

Why Choose the CD4060 14-Stage Binary Counter IC?

The CD4060 IC stands out as a cost-effective and reliable solution for designers who need both an oscillator and a binary counter in a single chip. Its ability to operate over a wide voltage range, combined with low power consumption and high noise immunity, makes it suitable for a broad range of applications—from simple hobby projects to industrial control systems.

With multiple divided outputs and flexible clock configuration, the CD4060 significantly reduces component count, simplifying circuit design and improving reliability. Whether you are building a digital timer, frequency divider, or clock generator, the CD4060 14-Stage Ripple Carry Binary Counter IC delivers dependable performance and design flexibility.

Package Includes:

1 x CD4060 14Stage Ripple Carry Binary Counter IC (DIP-16 Package)
