CD4099 8 bit Addressable Latch IC is a versatile CMOS logic integrated circuit designed for reliable digital data storage and output control. It allows individual addressing and latching of eight separate outputs using minimal control lines, making it ideal for memory expansion, I/O control, and digital system design. With low power consumption, wide operating voltage range, and excellent noise immunity, the CD4099 IC is widely used in embedded systems, industrial electronics, and educational projects.
Manufactured using advanced CMOS technology, the CD4099 ensures stable performance even in electrically noisy environments. Each output can be independently latched and held until updated, providing efficient control of multiple devices without continuous microcontroller intervention. This makes the CD4099 a preferred choice for designers seeking simplicity, flexibility, and energy efficiency.
Key Features of CD4099 8-Bit Addressable Latch IC
-
8-Bit Addressable Output Latch
Allows selective control of eight independent outputs using address inputs. -
CMOS Technology
Ensures ultra-low static power consumption and high noise immunity. -
Wide Operating Voltage Range
Operates reliably from 3 V to 15 V, suitable for both low-voltage and standard logic systems. -
Latched Outputs
Outputs retain their states even after control signals are removed. -
Direct Output Drive Capability
Can directly interface with LEDs, relays, and other logic circuits. -
High Noise Margin
Suitable for industrial and harsh electrical environments. -
TTL Compatible Inputs
Easily interfaces with microcontrollers, microprocessors, and TTL logic families. -
Compact 16-Pin DIP Package
Easy to mount on PCBs and breadboards for prototyping and production.
CD4099 IC Specifications
| Parameter | Description |
|---|---|
| IC Type | 8-Bit Addressable Latch |
| Logic Family | CMOS |
| Operating Voltage | 3 V to 15 V |
| Number of Outputs | 8 |
| Address Inputs | 3 |
| Data Input | 1 |
| Enable Control | 1 |
| Output Type | Latched CMOS |
| Input Compatibility | TTL / CMOS |
| Power Consumption | Very Low (Static CMOS) |
| Operating Temperature | –55°C to +125°C |
| Package Type | 16-Pin DIP |
| Manufacturer Series | CD4000 Series |
How the CD4099 Addressable Latch Works
The CD4099 uses three address lines to select one of eight outputs. A single data input and enable signal control the selected output, allowing it to be set HIGH or LOW. Once latched, the output maintains its state independently, freeing the control system for other tasks. This efficient addressing scheme reduces pin usage and simplifies circuit design.
Applications of CD4099 8-Bit Addressable Latch IC
The CD4099 IC is widely used in various digital and control applications, including:
-
Microcontroller I/O Expansion
Increase the number of output pins using minimal MCU resources. -
LED and Display Control
Ideal for driving LED indicators, status panels, and segment displays. -
Relay and Load Control Systems
Latch control signals for relays, solenoids, and switching devices. -
Memory and Register Storage
Temporary data storage in digital systems and control logic. -
Industrial Automation
Used in control panels and signal routing systems. -
Embedded Systems and Robotics
Simplifies control of multiple actuators and peripherals. -
Educational and DIY Electronics Projects
Perfect for learning digital logic, addressing, and latch operation.
Why Choose the CD4099 8-Bit Addressable Latch IC?
The CD4099 IC stands out for its simplicity, reliability, and energy efficiency. It minimizes wiring complexity while providing precise control over multiple outputs. Its wide voltage compatibility makes it suitable for both modern low-power systems and traditional logic circuits. Whether you are designing an industrial controller, embedded application, or academic project, the CD4099 offers a cost-effective and proven solution.
Order the CD4099 8-Bit Addressable Latch IC today and enhance your digital designs with efficient, low-power output control.
Package Includes:
1 x CD4099 8 bit Addressable Latch IC (DIP-16 Package)
FAQ
1. Where can we buy this CD4099 8 bit Addressable Latch IC?
This product is available online https://aiiottech.in/product/cd4099-8-bit-addressable-latch-ic/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103
2. When can I get this CD4099 8 bit Addressable Latch IC after placing the order?
RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.
