Micro USB Breakout Board (Power Charging Module)

Micro USB Breakout Board (Power Charging Module) is a compact, reliable, and easy-to-use solution for powering and charging your embedded systems, IoT prototypes, and development boards. Designed for engineers, hobbyists, students, and product developers, this module simplifies power integration by breaking out the standard Micro USB interface into clearly labeled, solderable pins. Whether you’re working with Arduino Uno, NodeMCU, Raspberry Pi Pico, or custom PCB designs, this breakout board ensures safe and stable 5V power delivery.

Built for durability and performance, the Micro USB Breakout Board is ideal for charging lithium battery circuits, powering microcontrollers, and supplying regulated 5V to low-power electronics projects. Its compact footprint makes it suitable for space-constrained applications, while the high-quality Micro USB connector guarantees consistent connectivity and long service life.

Key Features

1. Standard Micro USB Interface

Equipped with a high-quality Micro USB female connector, this module allows easy connection to standard USB chargers, power banks, laptops, and USB adapters.

2. Stable 5V Power Output

Delivers regulated 5V output directly from a USB source, suitable for most microcontroller boards and development platforms.

3. Clearly Labeled Pins

The breakout pins are clearly marked for:

• VBUS (5V)

• GND

• D+

• D–

• ID (if available)

This simplifies integration into breadboards, perfboards, and custom PCB circuits.

4. Compact & Lightweight Design

Small PCB footprint allows integration into portable devices, DIY electronics, and embedded systems without increasing size or weight.

5. Easy Soldering

Standard 2.54mm pitch header holes ensure compatibility with common headers and jumper wires.

6. Reliable Charging Support

Suitable for powering and charging battery management modules such as TP4056-based Li-ion charging circuits.

7. Durable PCB Construction

Manufactured with high-quality FR4 PCB material and strong solder pads for long-lasting performance.

Technical Specifications

• Connector Type: Micro USB Female

• Input Voltage: 5V DC (via USB)

• Output Voltage: 5V DC

• Maximum Current: Up to 1A–2A (depending on USB source)

• Pin Pitch: 2.54mm standard header spacing

• Board Material: FR4

• Mounting: Through-hole header compatible

• Operating Temperature: -20°C to +70°C

• Board Dimensions: Compact form factor (approx. 20mm × 15mm, may vary slightly)

Applications

The Micro USB Breakout Board (Power Charging Module) is versatile and widely used across multiple electronics applications:

🔹 1. IoT & Embedded Systems

Perfect for powering ESP8266, ESP32, and other IoT modules in smart home, industrial monitoring, and wireless sensor network projects.

🔹 2. Arduino & Microcontroller Projects

Easily power development boards such as Arduino Nano and custom ATmega-based circuits directly from USB adapters.

🔹 3. Battery Charging Systems

Works seamlessly with lithium-ion battery charging modules like TP4056 for portable electronics, power banks, and wearable devices.

🔹 4. DIY Electronics & Prototyping

Ideal for breadboard testing, electronics lab experiments, academic research, and engineering student projects.

🔹 5. Robotics Projects

Provides reliable 5V input for small robots, motor driver logic circuits, and control boards.

🔹 6. Portable Gadgets

Useful in handheld devices, USB-powered gadgets, LED lighting systems, and custom enclosures requiring compact power input.

Why Choose This Micro USB Breakout Board?

✔ Plug-and-play USB power integration
✔ Safe and reliable 5V supply
✔ Compact and space-saving design
✔ Perfect for prototyping and production
✔ Cost-effective power solution
✔ Compatible with common USB chargers and power banks

This Micro USB Power Charging Module eliminates the need for complex USB connector soldering and ensures safe, organized power distribution in your electronics projects.

Order Now

Upgrade your electronics projects with a reliable and easy-to-use Micro USB Breakout Board (Power Charging Module). Whether you’re designing IoT devices, student projects, robotics systems, or custom PCBs, this module provides a clean, stable, and efficient USB power interface for your next innovation.

Package Includes:

1 x Micro USB Breakout Board (Power Charging Module)

FAQ

1. Where can we buy this Micro USB Breakout Board (Power Charging Module)?

This product is available online https://aiiottech.in/product/micro-usb-breakout-board/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this Micro USB Breakout Board (Power Charging Module) after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: Micro Usb 5Pin Female Connector
