XL6009 Boost Module

XL6009 Boost Module is a powerful and reliable DC-DC step-up (boost) voltage converter designed for electronics hobbyists, engineers, and embedded system developers who require stable and adjustable output voltage from low-voltage sources. Built around the high-performance XL6009 switching regulator IC, this module efficiently boosts input voltages as low as 3V to higher regulated outputs up to 35V, making it ideal for battery-powered projects, renewable energy systems, robotics, and portable devices.

With its compact design, onboard high-current inductor, fast Schottky diode, and adjustable potentiometer, the XL6009 module ensures high efficiency, low ripple, and stable output under varying load conditions. Whether you are powering sensors, microcontrollers, motors, LEDs, or communication modules, this boost converter provides a cost-effective and dependable power solution.

Key Specifications

• Input Voltage Range: 3V – 32V DC

• Output Voltage Range: 5V – 35V DC (adjustable via onboard potentiometer)

• Maximum Output Current: Up to 4A (peak), recommended 2A continuous

• Conversion Efficiency: Up to 94%

• Switching Frequency: 400kHz

• Chipset: XL6009 Step-Up Switching Regulator

• Protection: Thermal shutdown and current limiting

• Ripple Voltage: Low ripple output with proper filtering

• Operating Temperature: -40°C to +85°C

• Module Dimensions: Approx. 43mm × 21mm × 14mm

• Mounting: Through-hole mounting points for secure installation

Key Features

🔋 High-Efficiency Boost Conversion

The XL6009 Boost Module delivers up to 94% efficiency, minimizing power loss and heat generation, making it ideal for battery-operated and portable applications.

⚡ Wide Input Voltage Range

Accepts input voltages from 3V to 32V, enabling step-up conversion from lithium-ion cells, AA batteries, solar panels, and low-voltage DC sources.

🎚️ Adjustable Output Voltage

The onboard multi-turn potentiometer allows easy and precise adjustment of output voltage between 5V and 35V, offering flexibility across various projects.

🔥 Built-In Protection

Equipped with overcurrent protection and thermal shutdown, the module safeguards connected loads and ensures long-term operational reliability.

📏 Compact and Easy to Integrate

Its compact PCB layout and standard pin configuration make it easy to integrate into breadboards, prototyping platforms, and embedded systems.

🔄 High Switching Frequency

Operating at 400kHz, the XL6009 reduces external component size requirements while delivering fast transient response and stable voltage regulation.

Applications

🔌 Battery-Powered Electronics

Ideal for boosting voltage from single-cell Li-ion or NiMH batteries to power microcontrollers, displays, wireless modules, and development boards.

🤖 Robotics and Automation

Perfect for robotics projects requiring higher voltage rails for motors, sensors, and control circuits from low-voltage battery packs.

💡 LED Drivers and Lighting Systems

Supports constant voltage LED drivers, portable lighting systems, and automotive LED applications where voltage step-up is needed.

☀️ Solar and Renewable Energy Systems

Efficiently boosts voltage from solar panels and energy harvesting devices to regulated DC levels for storage or load applications.

📡 IoT and Embedded Systems

Used extensively in IoT nodes, embedded controllers, GPS modules, and communication devices, ensuring stable voltage delivery in compact designs.

🔧 DIY Electronics and Prototyping

A must-have module for makers, students, and hobbyists, enabling rapid power supply design for Arduino, Raspberry Pi, ESP32, and custom circuits.

Why Choose the XL6009 Boost Module?

The XL6009 Boost Converter Module offers an excellent balance of performance, efficiency, reliability, and affordability. Unlike linear regulators that waste energy as heat, this switching boost converter maximizes energy efficiency while delivering high current output. Its wide voltage compatibility and adjustable output make it a versatile solution for multiple electronic projects.

Compared to similar boost modules, the XL6009 stands out due to its high switching frequency, stable load regulation, compact size, and thermal protection, ensuring dependable performance even in demanding conditions. Whether you are building industrial prototypes or consumer electronics, this module delivers professional-grade power management in a compact form factor.

Package Includes:

1 x XL6009 Boost Module

FAQ

1. Where can we buy this XL6009 Boost Module?

This product is available online https://aiiottech.in/product/xl6009-boost-module/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this XL6009 Boost Module after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: XL6009 DC-DC Step-up Module
