74HC153 Dual 1-of-4 Line Data Selector IC (DIP-16 Package)

74HC153 Dual 1-of-4 Line Data Selector IC is a high-performance CMOS multiplexer designed for reliable data routing and digital signal selection in modern electronic systems. This integrated circuit contains two independent 4-to-1 multiplexers within a single package, making it an efficient and space-saving solution for complex digital logic applications.

Built using High-Speed CMOS (HC) technology, the 74HC153 offers low power consumption, high noise immunity, and fast switching speeds, making it ideal for microcontroller-based systems, embedded designs, and educational electronics projects. It operates over a wide supply voltage range and is fully compatible with TTL logic levels, ensuring seamless integration into both legacy and modern digital circuits.

Each multiplexer section has four data inputs, common select lines, and an active-LOW enable input, allowing flexible control over signal selection. The dual structure enables simultaneous handling of two independent data channels, reducing component count and improving overall system reliability.

Key Features of 74HC153 IC

• Dual 4-to-1 Multiplexer in a single IC

• High-Speed CMOS (HC) Technology for fast data switching

• Low Power Consumption suitable for battery-powered devices

• Wide Operating Voltage Range (2V to 6V)

• TTL-Compatible Inputs for easy interfacing

• Independent Active-LOW Enable Inputs for each multiplexer

• High Noise Immunity for stable digital performance

• Compact DIP/SOIC Package Options

• Ideal for signal routing, data selection, and logic control

Technical Specifications

Working Principle

The 74HC153 IC uses two common select inputs (S0 and S1) to choose one of the four data inputs for each multiplexer. Depending on the binary combination applied to the select lines, the corresponding input is routed to the output. Each multiplexer can be independently enabled or disabled using its active-LOW enable pin, offering greater design flexibility.

This architecture allows the IC to efficiently perform data multiplexing, signal routing, and logic function implementation without additional external components.

Applications of 74HC153 Dual 1-of-4 Multiplexer

The 74HC153 IC is widely used across various digital and embedded applications, including:

• Microcontroller and Microprocessor Systems

• Digital Signal Routing and Switching

• Data Bus Selection and Control

• Embedded System Design

• Logic Circuit Implementation

• Communication Systems

• Educational Electronics and Lab Experiments

• Industrial Control Systems

• Test and Measurement Equipment

• Memory Address and Data Selection

Its dual-channel capability makes it especially useful where multiple signals must be selected simultaneously, reducing board space and component cost.

Why Choose 74HC153 IC?

The 74HC153 Dual 1-of-4 Line Data Selector IC delivers an excellent balance of speed, efficiency, and reliability. With its low power consumption, wide voltage compatibility, and robust CMOS performance, it is a preferred choice for students, hobbyists, and professional engineers alike. Whether you are designing a compact embedded system or experimenting with digital logic circuits, this IC provides consistent and predictable performance.

Order the 74HC153 Dual 1-of-4 Line Data Selector IC today to simplify your digital designs with high-speed, low-power signal selection and dependable CMOS technology.

Package Includes:

1 x 74HC153 Dual 1-of-4 Line Data Selector IC (DIP-16 Package)
