74HC157 Quad 2-Input Multiplexer IC (DIP-16 Package)

74HC157 Quad 2-Input Multiplexer IC is a high-performance CMOS logic device designed for efficient digital data selection and signal routing. It integrates four independent 2-to-1 multiplexers in a single package, allowing designers to select between two sets of data inputs using a common select line. With low power consumption, high noise immunity, and fast switching speeds, the 74HC157 is an ideal choice for modern digital and embedded system applications.

This IC belongs to the 74HC (High-Speed CMOS) logic family, offering full compatibility with TTL logic levels while delivering superior power efficiency compared to traditional TTL devices. The presence of a common active-LOW enable (strobe) input allows all outputs to be disabled simultaneously, making it suitable for bus-oriented architectures and data multiplexing tasks.

Key Features of 74HC157 Quad 2-Input Multiplexer IC

• Quad 2-to-1 Multiplexer Architecture
  Four independent data channels allow simultaneous selection of multiple signals.

• Common Select and Enable Inputs
  A single select line chooses between A or B inputs, while the active-LOW enable controls all outputs.

• High-Speed CMOS Technology
  Ensures fast propagation delays and reliable performance in high-frequency digital systems.

• Low Power Consumption
  CMOS design significantly reduces static and dynamic power usage.

• Wide Operating Voltage Range
  Operates from 2V to 6V, making it suitable for both 3.3V and 5V logic systems.

• TTL-Compatible Inputs
  Can interface directly with TTL and other CMOS logic families.

• High Noise Immunity
  Provides stable operation even in electrically noisy environments.

• Standard DIP and SMD Packages
  Available in DIP-16, SOIC-16, and TSSOP-16 for easy prototyping and PCB integration.

Specifications

• Logic Type: Quad 2-Input Multiplexer

• Number of Channels: 4

• Inputs per Channel: 2 (A and B)

• Select Input: 1 (Common)

• Enable Input: 1 (Active LOW)

• Output Type: CMOS Push-Pull

• Operating Voltage (Vcc): 2V to 6V

• Input Logic Level: TTL / CMOS compatible

• Propagation Delay: Typically 8–15 ns (depending on Vcc)

• Operating Temperature Range: –40°C to +85°C

• Package Types: DIP-16, SOIC-16, TSSOP-16

Applications of 74HC157 Quad 2-Input Multiplexer IC

The 74HC157 IC is widely used in digital and embedded designs where efficient signal selection and data routing are required. Common applications include:

• Microcontroller and Microprocessor Systems
  Used to select between multiple data sources or address lines.

• Data Bus Multiplexing
  Ideal for sharing data buses in complex digital systems.

• Embedded Systems and IoT Devices
  Low power consumption makes it suitable for battery-powered designs.

• Digital Signal Routing
  Simplifies logic design by reducing the number of discrete components.

• Communication Systems
  Used in data selection, control logic, and channel switching.

• Memory Address and Data Selection
  Enables efficient selection between different memory banks.

• Educational and Training Projects
  Commonly used in electronics labs, logic design experiments, and academic projects.

• Industrial Control Systems
  Reliable operation across wide temperature ranges ensures industrial suitability.

Why Choose the 74HC157?

The 74HC157 Quad 2-Input Multiplexer IC offers an excellent balance of speed, power efficiency, and design simplicity. Its ability to handle multiple data channels with a single select line reduces PCB complexity and component count. With wide voltage compatibility and robust noise immunity, it is a dependable choice for both professional engineers and hobbyists.

Whether you are designing embedded hardware, digital logic circuits, or educational projects, the 74HC157 provides consistent performance and long-term reliability.

Package Includes:

1 x 74HC157 Quad 2-Input Multiplexer IC (DIP-16 Package)
