74LS86 Quad 2 Input Exclusive OR Gate IC

74LS86 Quad 2 Input Exclusive OR Gate IC is a widely used TTL (Transistor-Transistor Logic) integrated circuit designed to perform exclusive-OR logic operations with high speed and reliability. This IC contains four independent XOR gates, each capable of accepting two binary inputs and producing a single output. The output becomes HIGH only when the inputs differ, making it an essential component in digital electronics, computing systems, communication circuits, and embedded applications.

Built using Low-Power Schottky (LS) technology, the 74LS86 offers faster switching speeds and reduced power consumption compared to standard TTL logic devices. It is compatible with other 74LS series ICs, ensuring seamless integration into existing digital logic designs. Owing to its robustness and ease of use, this IC is commonly found in educational labs, industrial electronics, and commercial digital systems.

74LS86 Quad 2-Input Exclusive-OR (XOR) Gate IC contains four independent XOR gates, each performing a basic exclusive-OR logic function. Each gate accepts two binary inputs and produces a HIGH output only when the inputs are different—one HIGH and the other LOW. When both inputs are the same, either HIGH or LOW, the output remains LOW. Built using Low-Power Schottky (LS) TTL technology, the 74LS86 provides fast switching speed and low power consumption. It operates with a 5V supply and is commonly used in digital comparison, arithmetic, parity checking, and error detection circuits.

Key Features of 74LS86 Quad XOR Gate IC

• Four Independent XOR Gates: Contains four 2-input exclusive-OR gates in a single 14-pin package

• Low Power Schottky Technology: Reduced power consumption with improved switching performance

• High-Speed Operation: Typical propagation delay of approximately 10 ns

• TTL Compatible Logic Levels: Fully compatible with standard 5V TTL systems

• Wide Operating Temperature Range: Suitable for industrial and commercial environments

• Standard DIP-14 Package: Easy to handle, breadboard-friendly, and ideal for prototyping

• Reliable and Stable Performance: Proven design for long-term digital logic applications

Technical Specifications

• IC Type: Quad 2-Input Exclusive-OR Gate

• Logic Family: TTL (74LS Series)

• Number of Gates: 4

• Inputs per Gate: 2

• Supply Voltage (Vcc): 5V (Typical)

• Input Voltage Range: 0V to 5.5V

• Output Voltage: TTL compatible

• Propagation Delay: ~10 ns (typical)

• Power Dissipation: Low power consumption due to LS technology

• Operating Temperature Range: 0°C to 70°C

• Package Type: DIP-14

• Mounting Type: Through-hole

Working Principle

Each XOR gate inside the 74LS86 produces a HIGH output only when its two inputs are different (i.e., one input is HIGH and the other is LOW). When both inputs are the same (both HIGH or both LOW), the output remains LOW. This unique logic behavior makes XOR gates ideal for comparison, parity checking, and arithmetic operations.

Applications of 74LS86 XOR Gate IC

The 74LS86 Quad XOR Gate IC is widely used across various digital electronics applications, including:

• Digital Comparators: Detects differences between binary data

• Parity Generators and Checkers: Ensures data integrity in communication systems

• Adders and Subtractors: Used in half-adder and full-adder circuits

• Error Detection Circuits: Identifies bit mismatches in data transmission

• Phase Detectors: Used in PLL and frequency comparison circuits

• Data Encryption and Decryption: Simple XOR-based logic for security applications

• Embedded Systems: Logic control and signal processing

• Educational and Training Labs: Ideal for learning digital logic concepts

Why Choose the 74LS86 Quad XOR Gate IC?

The 74LS86 remains a popular choice due to its reliability, speed, and ease of integration. Its compatibility with the 74LS family makes it suitable for legacy systems as well as new digital designs. Whether you are a student, hobbyist, or professional engineer, this IC provides consistent performance for a wide range of logic applications.

Package Includes:

1 x 74LS86 Quad 2 Input Exclusive OR Gate IC

FAQ

1. Where can we buy this 74LS86 Quad 2 Input Exclusive OR Gate IC?

This product is available online  https://aiiottech.in/product/74ls86-quad-2-in…xclusive-or-gate/  and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this 74LS86 Quad 2 Input Exclusive OR Gate IC after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: TTL Logic Chips 74LS86 Quad 2 Input Exclusive OR Gates
