8CH 24MHz USB Logic Analyzer

8CH 24MHz USB Logic Analyzer is a compact, ultra-reliable, and versatile debugging tool designed for professionals, students, and electronics enthusiasts who work with digital circuits, embedded systems, and communication protocols. Engineered for high-speed signal capture and accurate data visualization, this logic analyzer offers exceptional performance in a sleek USB-powered module. Whether you are developing microcontroller-based systems, reverse-engineering digital devices, or testing communication buses, this analyzer is the perfect companion for fast, accurate, and efficient digital signal analysis.

With 8 independent input channels and a sampling rate of up to 24MHz, it captures complex digital events with remarkable clarity. The plug-and-play USB interface allows easy connectivity with computers, while the included open-source compatible software (such as PulseView or Sigrok) provides powerful decoding, triggering, and visualization features. This makes it an affordable yet highly capable logic analyzer for both beginners and experts who seek professional-grade debugging functionality without expensive lab equipment.

Key Features

✔ 8 Digital Channels

Capture and analyze signals from multiple digital sources simultaneously. Ideal for debugging multi-pin communication buses.

✔ High Sampling Rate (Up to 24MHz)

The 24MHz sampling speed ensures precise capture of fast digital pulses, serial data streams, and high-frequency switching circuits.

✔ USB Plug-and-Play Interface

USB-powered design eliminates external power supplies. Simply plug the device into your PC, install the software, and start analyzing signals instantly.

✔ Compatible with Open-Source Analysis Software

Works seamlessly with PulseView and Sigrok, offering protocol decoding, trigger functions, visualization tools, and data export options.

✔ Compact and Lightweight

Portable design makes it easy to carry for classroom use, field debugging, DIY projects, or professional development work.

✔ Wide Protocol Support

Supports popular protocols such as UART, I2C, SPI, 1-Wire, CAN, and more through software decoders.

✔ Affordable & Beginner-Friendly

Provides professional-grade capabilities at a budget-friendly price—ideal for students, hobbyists, and embedded system developers.

Specifications

• Channels: 8 digital input channels

• Maximum Sampling Rate: 24MHz

• Input Voltage Range: 0–5V digital signals

• Input Impedance: High-impedance CMOS/TTL compatible

• Communication Interface: USB 2.0

• Supported Protocol Decoders: UART, SPI, I2C, I2S, CAN, LIN, 1-Wire, JTAG, and more via software

• Supported Software: PulseView, Sigrok suite

• Operating System: Windows / Linux / macOS

• Power Source: USB-powered

• Status Indicator: LED activity light

• Included Accessories: 8-channel test wires, USB cable, grabber clips

• Dimensions: Compact pocket-sized enclosure

Applications

✔ Embedded System Debugging

Ideal for analyzing microcontroller signals (Arduino, STM32, ESP32, PIC, AVR) and debugging firmware timing issues.

✔ Communication Protocol Analysis

Effortlessly decode serial protocols like SPI, I2C, UART, CAN, and more for hardware development and troubleshooting.

✔ Digital Circuit Testing

Monitor logic levels, timing relationships, state transitions, and bus states in digital electronics.

✔ Educational & Research Projects

Perfect for engineering students and researchers working on digital electronics, signal processing, and embedded systems.

✔ Product Development & Prototyping

Accelerates testing cycles in R&D labs developing IoT devices, automation modules, robotics systems, and consumer electronics.

✔ Reverse Engineering & Device Inspection

Capture and analyze digital communication from unknown or legacy devices for reverse engineering and repair.

Why Choose the 8CH 24MHz USB Logic Analyzer?

This logic analyzer offers exceptional value, combining precision, speed, and flexibility in a compact USB-powered device. Its compatibility with widely used open-source tools, along with support for dozens of protocol decoders, makes it a must-have debugging instrument for anyone involved in digital electronics. From classroom learning to professional product development, the 8CH 24MHz USB Logic Analyzer delivers reliable, efficient, and highly accurate signal analysis at an unbeatable price.
