CD4010 Hex Buffer/Converter IC (DIP-16 Package)

CD4010 Hex Buffer/Converter IC is a high-performance CMOS logic level buffer designed to interface circuits operating at different voltage levels. Widely used in digital electronics, embedded systems, and industrial control applications, the CD4010 provides reliable signal buffering and voltage level conversion while maintaining low power consumption and excellent noise immunity.

Manufactured using advanced CMOS technology, the CD4010 features six independent non-inverting buffer stages, allowing a single IC to handle multiple signal lines simultaneously. Each buffer can accept a wide range of input voltages and translate them to a higher output logic level, making this IC an ideal choice for logic level shifting between TTL, CMOS, and microcontroller-based systems.

The CD4010 is particularly useful when low-voltage logic signals must drive higher-voltage CMOS devices without signal distortion. Its robust design ensures stable operation across a wide supply voltage range, making it suitable for both commercial and industrial electronics.

Key Features of CD4010 Hex Buffer / Converter IC

• Six Independent Non-Inverting Buffers
  Enables buffering and level conversion of up to six digital signals within a single IC.

• Wide Operating Voltage Range
  Supports high-voltage CMOS operation, typically up to 15 V, offering excellent flexibility in mixed-voltage designs.

• Logic Level Conversion Capability
  Allows low-voltage input signals to safely drive higher-voltage CMOS logic circuits.

• High Noise Immunity
  CMOS architecture ensures strong resistance to electrical noise and signal interference.

• Low Power Consumption
  Ideal for battery-powered and energy-efficient electronic systems.

• High Input Impedance
  Minimizes loading effects on preceding circuit stages.

• Standard DIP and Surface-Mount Packages
  Available in PDIP, SOIC, and TSSOP packages for easy integration into prototypes and production designs.

Technical Specifications – CD4010 IC

• IC Type: Hex Buffer / Logic Level Converter

• Logic Family: CMOS (4000 Series)

• Number of Buffers: 6

• Logic Function: Non-Inverting Buffer

• Supply Voltage (VDD): 3 V to 15 V

• Input Voltage Range: 0 V to VDD

• Output Voltage Range: 0 V to VDD

• Output Drive Capability: CMOS compatible

• Propagation Delay: Typically 60 ns (at 10 V)

• Operating Temperature Range: –40°C to +85°C

• Package Types: DIP-16, SOIC-16, TSSOP-16

• Technology: Complementary MOS (CMOS)

Electrical characteristics may vary slightly depending on manufacturer and operating conditions.

Applications of CD4010 Hex Buffer / Converter IC

The CD4010 IC is a versatile component used in a wide variety of digital and mixed-signal applications. Its ability to buffer and convert logic levels makes it indispensable in many electronic designs:

• Logic Level Shifting
  Converts low-voltage logic signals from microcontrollers or sensors to higher-voltage CMOS levels.

• Signal Buffering
  Prevents signal degradation when driving multiple loads or long PCB traces.

• Microcontroller Interfacing
  Acts as a safe interface between microcontrollers and higher-voltage peripheral devices.

• Industrial Control Systems
  Used in PLC interfaces, relay driver logic, and industrial automation panels.

• Digital Communication Circuits
  Improves signal integrity in clock distribution and data buffering applications.

• Consumer Electronics
  Found in calculators, timers, display drivers, and general digital logic circuits.

• Educational & DIY Projects
  Popular in electronics training labs and hobbyist projects for learning digital logic concepts.

Why Choose the CD4010 Hex Buffer / Converter IC?

The CD4010 stands out for its reliability, flexibility, and ease of use. Its wide voltage range and CMOS-based design make it an excellent solution for modern mixed-voltage systems. With six independent buffers in one compact package, it reduces component count, PCB space, and overall system cost.

Whether you are designing a commercial product, an industrial controller, or a DIY electronics project, the CD4010 Hex Buffer/Converter IC delivers stable performance, efficient power usage, and dependable logic level conversion.

Upgrade your digital designs with the CD4010 IC—a trusted and time-tested solution for clean, reliable, and efficient signal buffering.

Package Includes:

1 x CD4010 Hex Buffer/Converter IC
