CD4072 Dual 4-Input OR Gate IC (DIP-14 Package)

CD4072 Dual 4-Input OR Gate IC is a reliable and efficient CMOS logic integrated circuit designed for digital logic applications requiring multiple OR operations in a compact form. This IC contains two independent 4-input OR gates, making it ideal for complex logic functions while minimizing component count and power consumption. Manufactured using CMOS technology, the CD4072 offers low static power dissipation, high noise immunity, and a wide operating voltage range, making it suitable for both consumer and industrial electronic designs.

Whether you are designing embedded systems, digital control circuits, logic decision networks, or educational electronics projects, the CD4072 IC provides consistent performance and long-term reliability. It is compatible with other 4000-series CMOS logic ICs, allowing easy integration into existing circuit designs.

Key Features of CD4072 Dual 4-Input OR Gate IC

• Dual 4-Input OR Gates
  Integrates two separate OR gates, each capable of handling four inputs, enabling complex logic functions with fewer components.

• CMOS Technology
  Offers ultra-low power consumption and excellent noise immunity compared to TTL logic families.

• Wide Operating Voltage Range
  Supports a supply voltage range of 3V to 18V, making it suitable for battery-powered and standard logic applications.

• High Noise Immunity
  Ensures stable operation even in electrically noisy environments.

• Low Static Power Dissipation
  Ideal for low-power designs and energy-efficient electronic systems.

• Standard DIP-14 Package
  Easy to handle, breadboard-friendly, and suitable for both prototyping and permanent PCB mounting.

• High Input Impedance
  Reduces loading effects on preceding circuit stages.

• Compatible with Other CMOS ICs
  Seamlessly interfaces with other CD4000-series logic ICs.

Specifications

Applications of CD4072 Dual 4-Input OR Gate IC

The CD4072 IC is widely used in both commercial and educational electronics projects due to its flexibility and reliability. Common applications include:

• Digital Logic Circuits
  Performs multi-input OR logic operations in combinational logic designs.

• Embedded Systems
  Used in decision-making logic and signal combination tasks.

• Industrial Control Systems
  Suitable for control panels, automation circuits, and signal processing units.

• Alarm and Security Systems
  Combines multiple sensor outputs into a single trigger signal.

• Timing and Sequencing Circuits
  Works with counters, flip-flops, and timers in control logic.

• Educational and Training Projects
  Ideal for learning digital electronics and logic gate concepts.

• Signal Conditioning Circuits
  Used for logical signal merging and control signal generation.

• Consumer Electronics
  Applied in low-power digital devices and control boards.

Why Choose CD4072 Dual 4-Input OR Gate IC?

The CD4072 Dual 4-Input OR Gate IC stands out due to its low power consumption, wide voltage compatibility, and robust CMOS design. It simplifies circuit layouts by reducing the number of individual logic components required, improving reliability and lowering overall system cost. Its ability to operate across a wide temperature and voltage range makes it a dependable choice for both hobbyists and professional engineers.

Whether you are building a prototype, upgrading an existing design, or teaching digital logic fundamentals, the CD4072 delivers dependable performance and long-term stability.

Package Includes:

1 x CD4072 Dual 4-Input OR Gate IC (DIP-14 Package)
