CD4082 Dual 4 Input AND Gate IC (DIP-14 Package)

CD4082 Dual 4 Input AND Gate IC is a high-performance CMOS logic integrated circuit designed to deliver reliable digital AND logic operations in a wide range of electronic applications. Featuring two independent 4-input AND gates on a single chip, the CD4082 offers efficient logic processing while maintaining low power consumption, making it ideal for both battery-powered and industrial electronic systems.

Manufactured using advanced CMOS (Complementary Metal-Oxide-Semiconductor) technology, the CD4082 provides excellent noise immunity, high input impedance, and stable operation over a wide voltage range. These characteristics make it suitable for use in digital control systems, embedded electronics, industrial automation, and educational projects.

Key Features of CD4082 Dual 4-Input AND Gate IC

• Dual 4-Input AND Gates: Contains two independent AND gates, each capable of processing four logic inputs.

• Wide Operating Voltage Range: Supports supply voltages from 3V to 15V, offering compatibility with both low-voltage and standard logic systems.

• Low Power Consumption: CMOS technology ensures minimal static power dissipation, ideal for energy-efficient designs.

• High Noise Immunity: Reliable performance in electrically noisy environments.

• High Input Impedance: Reduces loading effects and improves signal integrity.

• TTL and CMOS Compatible Inputs: Seamless interfacing with various logic families.

• Stable Operation Over Temperature Range: Designed for consistent performance under varying environmental conditions.

• Standard DIP-14 Package: Easy to handle, breadboard-friendly, and suitable for through-hole PCB mounting.

Technical Specifications

• Product Name: CD4082 Dual 4-Input AND Gate IC

• Logic Function: AND

• Number of Gates: 2

• Inputs per Gate: 4

• Logic Family: CMOS

• Operating Supply Voltage (VDD): 3V to 15V

• Operating Temperature Range: –55°C to +125°C

• Power Dissipation: Very low static power consumption

• Propagation Delay: Low delay for standard CMOS logic

• Package Type: DIP-14

• Mounting Type: Through-hole

• Pin Configuration: Standard CD4000 series pinout

Applications of CD4082 Dual 4-Input AND Gate IC

The versatility and reliability of the CD4082 make it suitable for a wide range of digital and logic-based applications, including:

1. Digital Logic Circuits

Used to implement complex AND logic functions in combinational logic circuits, counters, and data processing systems.

2. Embedded Systems

Ideal for microcontroller-based systems where multiple input conditions must be met before triggering an output.

3. Industrial Automation

Commonly employed in control panels, safety interlocks, and signal validation circuits, ensuring outputs are activated only when all conditions are satisfied.

4. Signal Gating and Control

Used in signal conditioning and gating applications, where multiple signals must be logically combined.

5. Educational and Training Projects

Widely used in electronics labs and academic projects to teach Boolean logic, logic gates, and CMOS circuit design.

6. Consumer Electronics

Applied in digital clocks, alarm systems, calculators, and control logic modules.

7. Battery-Powered Devices

Low power consumption makes it suitable for portable and battery-operated electronic devices.

Why Choose CD4082 Dual 4-Input AND Gate IC?

The CD4082 stands out for its flexibility, efficiency, and reliability. With its ability to operate over a wide voltage range and maintain low power usage, it simplifies circuit design while improving overall system stability. Its dual-gate configuration reduces component count, saving PCB space and cost.

Whether you are a professional electronics engineer, student, or hobbyist, the CD4082 Dual 4-Input AND Gate IC is a dependable choice for implementing precise AND logic functions in modern electronic designs.

Package Includes:

1 x CD4082 Dual 4 Input AND Gate IC (DIP-14 Package)
