Hall Effect Sensor

Hall Effect Sensor is a high-precision magnetic sensor designed to detect magnetic fields and convert them into measurable electrical signals. Known for its reliability, compact design, and rapid response time, this sensor is an essential component in automotive systems, robotics, industrial automation, and electronic devices.

Engineered with advanced semiconductor technology, the Hall Effect Sensor offers accurate, non-contact detection, making it ideal for applications where durability and precision are crucial. Its versatility, sensitivity, and easy integration make it a go-to solution for engineers, hobbyists, and manufacturers alike.

Key Features of Hall Effect Sensor

• Non-Contact Sensing
  Detects magnetic fields without physical contact, reducing wear and tear while enhancing longevity.

• High Sensitivity & Precision
  Responds accurately to small changes in magnetic fields, ensuring precise measurement and control.

• Fast Response Time
  Capable of detecting changes in milliseconds, making it suitable for high-speed applications.

• Compact & Lightweight Design
  Small form factor allows easy integration into compact electronics, robotic assemblies, and automotive components.

• Wide Voltage & Current Range
  Compatible with low-voltage circuits and widely used microcontrollers, providing flexible application options.

• Durable and Reliable
  Resistant to mechanical wear and environmental factors, ensuring consistent performance over time.

• Digital & Analog Output Options
  Available in both digital (switching) and analog output versions, supporting various control systems and interfaces.

• Energy Efficient
  Low power consumption allows integration into battery-operated devices and energy-sensitive applications.

Technical Specifications – Hall Effect Sensor

• Sensor Type: Hall Effect Magnetic Sensor

• Operating Voltage: Typically 3.3 V to 24 V (varies by model)

• Output Type: Digital (ON/OFF) or Analog (voltage proportional to magnetic field)

• Detection Type: Unipolar, Bipolar, or Omnipolar (depending on variant)

• Response Time: < 10 µs for high-speed switching models

• Operating Temperature: –40°C to +150°C

• Current Consumption: 4–20 mA (typical)

• Package Type: TO-92, SIP, or SMD (surface mount)

• Magnetic Sensitivity: Typically 10–50 mT (millitesla)

• Durability: Solid-state design with no moving parts

Note: Specifications may vary depending on sensor variant and manufacturer.

Applications of Hall Effect Sensor

The Hall Effect Sensor is widely used across multiple industries and DIY projects due to its reliability, precision, and non-contact operation. Common applications include:

• Automotive Systems
  Detects wheel speed, crankshaft and camshaft positions, gear shifts, and anti-lock braking system (ABS) operations.

• Industrial Automation
  Monitors conveyor systems, motor rotation, proximity sensing, and machinery positioning with high accuracy.

• Robotics & Mechatronics
  Provides precise feedback for motor control, robotic arms, and automated machinery.

• Consumer Electronics
  Utilized in smartphones, tablets, laptops, and smart appliances for open/close detection and rotational sensing.

• Magnetic Encoders & Position Sensors
  Measures linear and rotary displacement in applications requiring accurate motion tracking.

• DIY & Educational Projects
  Popular in hobby electronics, Arduino, and Raspberry Pi projects for learning about magnetic sensing and control systems.

• Safety & Security Systems
  Employed in door sensors, window alarms, and access control systems for reliable proximity detection.

Why Choose Hall Effect Sensors?

Hall Effect Sensors combine precision, durability, and versatility in a compact package. Their ability to detect magnetic fields without physical contact ensures long-lasting, maintenance-free operation. Compatible with a wide range of microcontrollers and electronic circuits, they are an ideal choice for both professional engineers and DIY enthusiasts.

Whether you are building a high-performance automotive system, developing industrial automation equipment, or creating innovative electronics projects, the Hall Effect Sensor provides accurate, fast, and reliable magnetic detection. Upgrade your system with this sensor and achieve enhanced precision, efficiency, and reliability.

Package Includes:

1 x Hall Effect Sensor

FAQ

1. Where can we buy this Hall Effect Sensor?

This product is available online https://aiiottech.in/product/hall-effect-sensor/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this Hall Effect Sensor after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.
