LM2596 Mini 360 Power Supply Step-Down Module is a compact, high-efficiency DC-DC buck converter designed to deliver stable and adjustable output voltage for a wide range of electronic projects. Built around the reliable LM2596 switching regulator IC, this Mini 360 module efficiently converts higher DC input voltages into lower, regulated output voltages with minimal heat generation and power loss.
Whether you are working on embedded systems, robotics, IoT prototypes, automotive electronics, or battery-powered applications, the LM2596 Mini 360 offers consistent performance, small form factor, and excellent energy efficiency—making it one of the most popular DC-DC step-down modules in the maker and industrial community.
Key Features
1. High-Efficiency Buck Conversion
The LM2596 Mini 360 module uses advanced switching regulation technology, offering up to 92% conversion efficiency under optimal conditions. Compared to linear regulators, it significantly reduces heat dissipation, making it ideal for power-sensitive applications.
2. Wide Input Voltage Range
This module supports a DC input range of 4V to 40V, making it suitable for various power sources including:
-
12V and 24V adapters
-
Lithium battery packs
-
Lead-acid batteries
-
Solar power systems
3. Adjustable Output Voltage
The onboard precision multi-turn potentiometer allows users to adjust the output voltage from 1.25V to 35V. This flexibility makes it ideal for powering:
-
Microcontrollers
-
Development boards
-
Sensors
-
Motors
-
LED strips
4. Compact Mini 360 Design
With its ultra-compact footprint, the Mini 360 module fits easily into space-constrained enclosures and portable devices. Its small size makes it a preferred choice for embedded and DIY electronics projects.
5. High Output Current Capability
The module can deliver up to 3A maximum output current (2A recommended for continuous operation with proper heat management), making it suitable for moderately high-power loads.
6. Built-In Protection Features
-
Thermal shutdown protection
-
Overcurrent protection
-
Short-circuit protection
These built-in safeguards ensure safe and reliable operation in demanding environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| IC Used | LM2596 Switching Regulator |
| Input Voltage | 4V – 40V DC |
| Output Voltage | 1.25V – 35V DC (Adjustable) |
| Maximum Output Current | 3A (2A recommended continuous) |
| Conversion Efficiency | Up to 92% |
| Switching Frequency | 150 kHz |
| Output Ripple | ≤ 30mV (typical) |
| Operating Temperature | -40°C to +85°C |
| Module Size | Approx. 43mm × 21mm × 14mm |
| Regulation Type | Non-Isolated Buck Converter |
Applications
The LM2596 Mini 360 Step-Down Module is widely used in both hobbyist and industrial electronics applications.
🔹 Embedded Systems & Microcontrollers
Power development boards such as Arduino, ESP modules, STM32 boards, and other microcontrollers from higher voltage sources like 12V batteries or adapters.
🔹 Robotics and Automation
Provides stable voltage to motors, drivers, and control circuits in robotic platforms and automation systems.
🔹 IoT and Smart Devices
Efficiently regulates power for IoT sensors, wireless communication modules, and edge devices that require steady low-voltage DC supply.
🔹 Automotive Electronics
Ideal for stepping down vehicle battery voltage (12V/24V) to 5V or 9V for dashcams, GPS modules, and embedded automotive controllers.
🔹 LED Drivers
Used to power LED strips and lighting systems where controlled lower voltage is required.
🔹 Battery-Powered Projects
Improves battery life in portable devices by providing high-efficiency voltage conversion with minimal power loss.
🔹 Solar Energy Systems
Works effectively in small solar-based projects where voltage regulation is needed between panels, charge controllers, and loads.
Why Choose the LM2596 Mini 360 Module?
-
Reliable performance with proven LM2596 IC
-
High efficiency and low heat generation
-
Adjustable output for versatile applications
-
Compact design suitable for tight installations
-
Cost-effective power regulation solution
The LM2596 Mini 360 Power Supply Step-Down Module is a dependable and efficient solution for anyone looking to regulate DC voltage in electronic systems. Whether you are a student, engineer, hobbyist, or system integrator, this module provides the flexibility, stability, and performance needed for modern electronic designs.
Upgrade your power management system today with the LM2596 Mini 360 and ensure stable, efficient, and reliable voltage conversion for all your projects.
Package Includes:
1 x LM2596 Mini 360 Power Supply Step-Down Module
