LM358 IC

LM358 IC is a high-performance, dual operational amplifier designed to deliver reliable analog signal processing in a wide range of electronic circuits. Renowned for its low power consumption, high gain, and versatile applications, the LM358 is a preferred choice for both hobbyists and professional engineers. Whether you are building signal conditioning circuits, audio amplifiers, or sensor interfaces, the LM358 ensures optimal performance and precision.

Specifications of LM358 IC:

• Device Type: Dual Operational Amplifier

• Supply Voltage Range: 3V to 32V (Single Supply) or ±1.5V to ±16V (Dual Supply)

• Input Offset Voltage: Typically 2mV

• Input Bias Current: 45nA typical

• Output Voltage Swing: Up to VCC – 1.5V

• Gain-Bandwidth Product: 1MHz

• Slew Rate: 0.3V/µs typical

• Operating Temperature Range: -40°C to +85°C

• Package Options: DIP-8, SOIC-8, TSSOP-8

• Low Power Consumption: Typically 0.5mA per amplifier

The LM358 is designed to operate from a single power supply over a wide voltage range, making it ideal for battery-operated and portable devices. Its ability to handle dual power supply configurations adds to its versatility in complex circuit designs.

Key Features of LM358 IC:

1. Dual Amplifier Design: Combines two independent high-gain operational amplifiers in a single package, reducing component count and saving PCB space.

2. Low Power Consumption: With a typical supply current of just 0.5mA per amplifier, the LM358 is highly energy-efficient, making it suitable for portable electronics and low-power applications.

3. Wide Supply Voltage Range: Operates seamlessly on both single and dual supply voltages, providing flexibility in circuit design.

4. High Gain and Precision: Offers a typical voltage gain of 100 dB, ensuring accurate amplification for weak analog signals.

5. Rail-to-Rail Output (Single Supply): Capable of swinging output voltage close to the ground, allowing for maximum utilization of the supply voltage in single-supply circuits.

6. Robust and Reliable: Low offset voltage, low bias current, and excellent thermal stability make it suitable for industrial and precision applications.

7. Easy Integration: Available in standard 8-pin DIP and surface-mount packages, compatible with most PCB designs.

Applications of LM358 IC:

The LM358 operational amplifier is widely used in both consumer electronics and industrial applications due to its versatile functionality. Key applications include:

1. Signal Conditioning Circuits: Amplifies small analog signals from sensors, ensuring accurate data processing. Ideal for temperature sensors, pressure sensors, and light sensors.

2. Active Filters: Can be used to design low-pass, high-pass, band-pass, and band-stop filters for audio processing, instrumentation, and communication systems.

3. Voltage Followers and Buffers: Provides impedance matching and signal isolation in analog circuits without signal loss.

4. Comparators: Acts as a voltage comparator for threshold detection, level shifting, and pulse generation in automation and monitoring systems.

5. Audio Amplifiers: Suitable for low-frequency audio amplification, preamplifier circuits, and tone control applications.

6. Oscillators and Waveform Generators: Used in designing sine, square, and triangular waveform generators for signal testing and function generation.

7. Battery-Powered Circuits: Low power operation makes LM358 ideal for portable measurement and instrumentation systems.

8. Industrial Automation: Used in motor control circuits, process control, and analog sensor interfacing.

9. Educational Projects: Popular in DIY electronics, microcontroller interfacing, and STEM learning kits.

Why Choose LM358 IC?

The LM358 IC is celebrated for its robustness, low power consumption, and dual amplifier functionality. Its ability to operate under single or dual supply voltages, coupled with high gain and precision, makes it an indispensable component for modern analog electronics. Whether designing complex industrial circuits or hobbyist projects, the LM358 offers reliability, versatility, and cost-effectiveness.

For engineers, students, and electronics enthusiasts seeking a reliable, low-power, and versatile dual operational amplifier, the LM358 IC is the ultimate choice. From sensor signal amplification to audio applications and industrial automation, its wide operating range, precision, and durability ensure it fits seamlessly into your design requirements. Invest in the LM358 IC today and elevate your analog circuit designs with unmatched efficiency and performance.

Package Includes:

1 x LM358 IC

FAQ

1. Where can we buy this LM358 IC?

This product is available online  https://aiiottech.in/product/lm358-ic/  and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this LM358 IC after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: LM358 IC (Dual comparator)
