TP4056 Battery Charger C Type Module with Protection

TP4056 Battery Charger C Type Module with Protection is a compact, high-efficiency charging solution designed specifically for single-cell lithium-ion (Li-ion) and lithium-polymer (Li-Po) batteries. Built around the reliable TP4056 charging IC, this module ensures accurate constant-current/constant-voltage (CC/CV) charging while providing essential safety protections such as overcharge, over-discharge, overcurrent, and short-circuit protection. With a modern USB Type-C interface, it offers convenient, fast, and stable power input, making it ideal for DIY electronics, portable devices, IoT projects, and battery-powered applications.

Whether you are building a power bank, wearable device, wireless sensor node, or embedded system, this TP4056 charger module ensures safe battery management, long battery life, and consistent performance. Its small form factor, plug-and-play design, and clear LED indicators make it a favorite choice among engineers, hobbyists, educators, and makers.

Key Features

• USB Type-C Input Port
  Provides reliable 5V input from modern chargers, adapters, laptops, or power banks.

• Integrated Battery Protection Circuit
  Includes DW01A and dual MOSFET protection ICs to safeguard against overcharge, over-discharge, short circuit, and overcurrent.

• Optimized CC/CV Charging Algorithm
  Delivers precise constant-current/constant-voltage charging to extend battery lifespan and improve safety.

• Adjustable Charging Current (Up to 1A)
  Default charging current is typically set to 1A and can be modified using an onboard resistor for smaller batteries.

• Dual LED Charging Indicators
  Red LED indicates charging in progress, and blue/green LED signals full charge completion.

• Compact & Lightweight Design
  Small PCB size allows easy integration into space-constrained projects.

• Automatic Charge Termination & Recharge
  Stops charging when battery reaches full voltage and resumes when voltage drops.

• Reverse Polarity & Thermal Protection
  Enhances operational safety and protects connected components.

Technical Specifications

• Charging IC: TP4056

• Input Voltage: 4.5V – 5.5V (USB Type-C)

• Battery Type: Single-cell 3.7V Li-ion / Li-Po rechargeable battery

• Charge Termination Voltage: 4.2V ±1%

• Maximum Charging Current: Up to 1A (adjustable)

• Charging Method: Constant Current / Constant Voltage (CC/CV)

• Protection Features: Overcharge, over-discharge, overcurrent, short circuit

• Status Indicators: Red (charging), Blue/Green (charged)

• Operating Temperature: -10°C to +85°C

• Board Size: Approx. 25mm × 19mm × 5mm

• Connector Type: USB Type-C

• Efficiency: High efficiency with low power dissipation

• Mounting Type: Through-hole pads / solder terminals

Applications

The TP4056 Battery Charger C Type Module with Protection is widely used across multiple electronics domains due to its simplicity, safety, and versatility:

1. DIY Power Banks
   Perfect for building custom power bank circuits using 18650 lithium-ion cells with integrated charging and protection.

2. Portable Electronics & Gadgets
   Ideal for Bluetooth speakers, MP3 players, GPS trackers, and handheld devices that require rechargeable batteries.

3. IoT & Embedded Systems
   Commonly used in ESP32, Arduino, Raspberry Pi Pico, and sensor-based projects powered by Li-ion/Li-Po batteries.

4. Wearable Electronics
   Compact size and safe charging make it suitable for smartwatches, fitness bands, medical wearables, and small consumer electronics.

5. Robotics & Automation Projects
   Supports mobile robots, line followers, drones, and battery-powered control systems.

6. Educational & Training Labs
   Widely used in engineering colleges and electronics labs for teaching battery management systems and power electronics fundamentals.

7. Solar Charging Systems
   Can be integrated into small solar-powered battery systems with regulated 5V input.

Why Choose TP4056 Type-C Module with Protection?

• Enhanced Safety: Built-in battery protection circuitry prevents damage, overheating, and battery degradation.

• Modern Connectivity: USB Type-C ensures wide compatibility with modern chargers and cables.

• Easy Integration: Plug-and-play design with clear input/output pads and LED indicators simplifies prototyping.

• Reliable Performance: Proven TP4056 IC delivers stable charging and long battery life.

• Cost-Effective Solution: Offers professional-grade battery management at an affordable price point.

Product Summary

The TP4056 Battery Charger C Type Module with Protection is a compact, efficient, and reliable charging solution for single-cell lithium batteries. With advanced safety features, USB Type-C input, adjustable charging current, and simple operation, it is the perfect choice for hobbyists, engineers, students, and product developers. Whether you’re building IoT devices, portable gadgets, robotics projects, or rechargeable consumer electronics, this module ensures safe and consistent power management every time.

Upgrade your battery-powered designs today with the TP4056 USB Type-C charging module — the smart choice for safe, fast, and reliable lithium battery charging.

Package Includes:

1 x TP4056 Battery Charger C Type Module with Protection
