TP4056 Li-ion Battery Charging Module

TP4056 Li-ion Battery Charging Module is a compact, reliable, and highly efficient charging solution designed specifically for single-cell 3.7V lithium-ion and lithium-polymer batteries. Widely used in electronics projects, DIY prototypes, power banks, IoT devices, and embedded systems, this module offers safe and accurate charging through a standard Micro-USB interface.

Powered by the TP4056 linear charger IC, this module provides a constant current / constant voltage (CC/CV) charging algorithm that ensures optimal battery performance and long service life. Its small form factor, onboard protection features, and user-friendly LED indicators make it ideal for both beginners and professionals working with rechargeable battery systems.

Key Features of TP4056 Charging Module

✔ Optimized Charging Performance

The TP4056 module delivers stable and precise charging for 3.7V Li-ion/Li-Po batteries. It charges batteries up to 4.2V ±1%, preventing overcharging and enhancing battery safety.

✔ Micro-USB Power Input

Equipped with a Micro-USB port, the module can be powered using mobile chargers, power banks, USB adapters, or computer USB ports, offering exceptional convenience and flexibility.

✔ Adjustable Charging Current

The charging current is programmable up to 1A using an onboard resistor. This allows customization based on battery capacity and application requirements.

✔ Integrated Protection Circuit (Selected Variants)

Many TP4056 modules include an overcharge, over-discharge, and short-circuit protection IC, making them ideal for portable and wearable electronics.

✔ LED Charging Status Indicators

Two onboard LEDs provide real-time charging status:

• Red LED – Charging in progress

• Blue/Green LED – Charging complete

This visual feedback simplifies system monitoring.

✔ Compact and Lightweight Design

With a small PCB footprint, the TP4056 module easily fits into space-constrained designs such as handheld devices and compact enclosures.

Technical Specifications

• Charging IC: TP4056

• Battery Type: Single-cell Li-ion / Li-Po

• Battery Voltage: 3.7V nominal

• Charge Termination Voltage: 4.2V ±1%

• Input Voltage: 4.5V – 5.5V

• Charging Current: Up to 1A (adjustable)

• Charging Method: CC/CV

• Input Connector: Micro-USB

• Protection: Overcharge, over-discharge, short-circuit (model dependent)

• Operating Temperature: –10°C to +85°C

• PCB Size: Compact, lightweight design

Applications of TP4056 Li-ion Charging Module

The TP4056 charging module is widely used across multiple electronic applications due to its reliability and ease of integration:

🔹 DIY Electronics Projects

Perfect for hobbyists and makers working on Arduino, Raspberry Pi, and ESP-based projects requiring rechargeable battery power.

🔹 Power Bank Circuits

Commonly used in DIY power bank designs for safely charging and managing single lithium cells.

🔹 IoT & Embedded Systems

Ideal for low-power IoT devices, wireless sensor nodes, and smart home applications where battery charging reliability is critical.

🔹 Portable Consumer Electronics

Used in Bluetooth speakers, wireless headphones, MP3 players, and other compact portable gadgets.

🔹 Wearable Electronics

Suitable for wearables and health monitoring devices due to its compact size and stable charging performance.

🔹 Educational & Training Kits

Frequently included in electronics lab kits and engineering education projects for teaching battery management concepts.

Why Choose the TP4056 Charging Module?

• Ensures safe and efficient charging

• Easy USB power compatibility

• Compact design for embedded applications

• Widely tested and trusted in the electronics community

• Cost-effective solution for battery management

Whether you are building a DIY prototype, upgrading an existing battery system, or designing a portable electronic device, the TP4056 Li-ion Battery Charging Module offers an excellent balance of performance, safety, and simplicity.

Buy the TP4056 Li-ion Battery Charging Module today and power your projects with confidence!

Package Includes:

1 x TP4056 Li-ion Battery Charging Module
