XH-M120 PAM8610 Dual Channel Audio Amplifier Board

XH-M120 PAM8610 Dual Channel Audio Amplifier is a compact, high-performance Class-D stereo amplifier module designed for delivering clear, powerful, and distortion-free audio output in space-constrained applications. Built around the reliable PAM8610 amplifier IC, this module offers excellent sound quality with high efficiency, making it ideal for DIY audio projects, portable speakers, multimedia systems, and embedded audio applications.

Engineered for modern audio needs, the XH-M120 amplifier module supports dual-channel stereo output while maintaining low heat dissipation and minimal power loss. Its compact PCB design and simple wiring requirements make it easy to integrate into both professional and hobbyist projects. Whether you are building a compact speaker system or upgrading an existing audio setup, this amplifier module ensures stable and high-quality sound performance.

Key Features of XH-M120 PAM8610 Audio Amplifier

• High-Efficiency Class-D Amplification
  Uses Class-D technology for high efficiency (up to 90%), reducing power consumption and heat generation.

• Dual Channel Stereo Output
  Delivers balanced left and right channel audio output for true stereo sound reproduction.

• Low Distortion & Clear Audio
  Provides low total harmonic distortion (THD), ensuring clean, crisp, and accurate sound output.

• Compact & Lightweight Design
  Small PCB footprint makes it suitable for space-limited enclosures and portable devices.

• Wide Input Voltage Range
  Operates efficiently across a broad DC voltage range, supporting multiple power supply options.

• Built-in Protection Features
  Includes over-temperature, short-circuit, and over-current protection for reliable operation.

• Easy Integration
  Clearly marked input, output, and power terminals simplify installation and wiring.

Technical Specifications – XH-M120 PAM8610

• Amplifier IC: PAM8610

• Amplifier Type: Class-D Stereo Audio Amplifier

• Number of Channels: 2 (Dual Channel)

• Rated Output Power:

  • Up to 2 × 10 W (depending on power supply and speaker impedance)

• Input Voltage Range: DC 7 V – 15 V

• Recommended Voltage: DC 12 V

• Speaker Impedance: 4 Ω – 8 Ω

• Efficiency: Up to 90%

• Total Harmonic Distortion (THD): ≤ 0.1% (typical)

• Signal-to-Noise Ratio (SNR): ≥ 90 dB

• Frequency Response: 20 Hz – 20 kHz

• Audio Input Type: Analog (L/R)

• PCB Type: Pre-assembled module

• Operating Temperature: –20°C to +70°C

Note: Output power depends on supply voltage, speaker impedance, and cooling conditions.

Applications of XH-M120 PAM8610 Dual Channel Amplifier

The XH-M120 PAM8610 audio amplifier module is suitable for a wide range of consumer, industrial, and educational applications, including:

• DIY Stereo Speaker Systems
  Ideal for building compact home or portable stereo speakers with high sound clarity.

• Bluetooth & Multimedia Speakers
  Commonly used in Bluetooth audio systems when paired with a wireless receiver module.

• TV, PC, and Laptop Audio Amplification
  Enhances audio output for monitors, PCs, and small entertainment systems.

• Embedded Audio Projects
  Perfect for integration into microcontroller-based systems such as Arduino, Raspberry Pi, and IoT devices.

• Portable Audio Devices
  Suitable for battery-powered projects due to high efficiency and low power consumption.

• Educational & Prototyping Use
  Widely used in electronics labs, training kits, and audio prototyping projects.

Why Choose the XH-M120 PAM8610 Audio Amplifier?

The XH-M120 PAM8610 Dual Channel Audio Amplifier stands out for its combination of compact size, high efficiency, and excellent audio performance. Unlike traditional Class-AB amplifiers, this Class-D module delivers higher output power with minimal heat generation, making it more reliable and energy-efficient.

Its wide voltage compatibility, stereo output capability, and built-in protection features make it a dependable choice for both beginners and professionals. Whether you are designing a custom audio system or upgrading an existing one, the XH-M120 amplifier module offers an affordable and powerful solution for high-quality sound amplification.

Upgrade your audio projects with the XH-M120 PAM8610 Dual Channel Audio Amplifier and enjoy efficient, clear, and powerful stereo sound in every application.

Package Includes:

1 x XH-M120 PAM8610 Dual Channel Audio Amplifier Board

FAQ

1. Where can we buy this XH-M120 PAM8610 Dual Channel Audio Amplifier Board?

This product is available online https://aiiottech.in/product/tda-2030a-audio-power-amplifier-module/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this XH-M120 PAM8610 Dual Channel Audio Amplifier Board after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: PAM 8610 mini Hi-Fi Amplifier board testing video
