BME680 Humidity Temp Pressure Sensor Module

BME680 Humidity Temp Pressure Sensor Module is a compact, high-precision environmental sensor developed by Bosch Sensortec for multi-parameter air quality and environmental monitoring. This all-in-one sensor integrates humidity, temperature, barometric pressure, and gas sensing capabilities into a single, low-power module, making it ideal for IoT applications, smart devices, weather monitoring, and industrial automation.

Designed for accuracy, reliability, and ease of integration, the BME680 sensor module supports both I²C and SPI communication interfaces, ensuring seamless compatibility with popular microcontrollers such as Arduino, Raspberry Pi, ESP8266, ESP32, STM32, and other embedded platforms. Its small footprint and low power consumption make it especially suitable for portable, battery-powered, and space-constrained applications.

Key Features of BME680 Sensor Module

• 4-in-1 Environmental Sensing
  Measures relative humidity, ambient temperature, barometric pressure, and gas resistance in a single compact module.

• High Accuracy & Stability
  Factory-calibrated sensors provide accurate and consistent readings over a wide operating range.

• Integrated Gas Sensor for Air Quality
  Detects volatile organic compounds (VOCs) and other gases, enabling air quality monitoring and indoor environment analysis.

• Low Power Consumption
  Optimized for energy-efficient operation, making it suitable for battery-powered IoT and wearable devices.

• Dual Communication Interface
  Supports both I²C and SPI interfaces for flexible system integration.

• Compact & Lightweight Design
  Small form factor allows easy installation in compact enclosures and embedded systems.

• Wide Platform Compatibility
  Works seamlessly with popular development boards and microcontrollers.

Technical Specifications – BME680 Sensor Module

• Sensor Type: Environmental Sensor (Humidity, Temperature, Pressure & Gas)

• Sensor Chip: Bosch BME680

• Humidity Range: 0 to 100 %RH

• Humidity Accuracy: ±3 %RH

• Temperature Range: –40°C to +85°C

• Temperature Accuracy: ±1.0°C

• Pressure Range: 300 to 1100 hPa

• Pressure Accuracy: ±1 hPa

• Gas Sensor Range: Up to 500 kΩ (gas resistance)

• Operating Voltage: 1.71 V to 3.6 V

• Interface: I²C and SPI

• I²C Address: 0x76 / 0x77 (configurable)

• Operating Current: Ultra-low power, typically in microamp range

• Module Output: Digital

• Operating Temperature: –40°C to +85°C

Note: Gas resistance readings are intended for relative air quality assessment and trend analysis rather than absolute gas concentration measurement.

Applications of BME680 Humidity Temp Pressure Sensor Module

Thanks to its versatile sensing capabilities, the BME680 sensor module is widely used in a broad range of commercial, industrial, and hobbyist applications:

• Indoor Air Quality Monitoring
  Ideal for smart homes, offices, and public buildings to monitor VOC levels and overall air quality.

• IoT & Smart Devices
  Used in IoT nodes, smart thermostats, weather stations, and connected environmental monitoring systems.

• Weather Monitoring Systems
  Measures temperature, humidity, and atmospheric pressure for local weather prediction and data logging.

• Industrial Automation & HVAC Systems
  Supports environment-aware control in heating, ventilation, and air conditioning systems.

• Wearable & Portable Devices
  Low power consumption makes it suitable for health, fitness, and portable environmental monitors.

• Agriculture & Greenhouse Monitoring
  Helps monitor humidity and temperature conditions for optimal plant growth.

• Educational & Research Projects
  Popular in academic labs, training kits, and DIY electronics projects for learning sensor integration.

Why Choose the BME680 Sensor Module?

The BME680 Humidity Temperature Pressure Sensor Module stands out due to its multi-sensor integration, high accuracy, compact size, and low power operation. By combining four critical environmental parameters into a single module, it reduces system complexity, saves board space, and lowers overall cost. Its reliable Bosch engineering ensures consistent performance, while flexible communication interfaces simplify software development and system design.

Whether you are developing a smart home system, IoT sensor node, weather station, or industrial monitoring solution, the BME680 sensor module provides a dependable and future-ready environmental sensing solution.

Upgrade your project with the BME680 Humidity Temp Pressure Sensor Module and achieve accurate, real-time environmental insights with ease.

Package Includes:

1 x BME680 Humidity Temp Pressure Sensor Module

FAQ

1. Where can we buy this BME680 Humidity Temp Pressure Sensor Module?

This product is available online https://aiiottech.in/product/emg-muscle-sensor-module-for-arduino/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this BME680 Humidity Temp Pressure Sensor Module after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: BME680 Digital Temperature Humidity Pressure Sensor
