BTS7960B 43A H-Bridge Motor Driver

BTS7960B 43A H-Bridge Motor Driver is a robust, high-current driver module designed for precise and efficient control of DC motors and stepper motors in robotics, automation, and industrial applications. Engineered with high-performance BTS7960B power ICs, this H-Bridge motor driver can handle up to 43A of continuous current, making it suitable for high-power motors, electric vehicles, robotics platforms, and heavy-duty machinery.

With its dual H-Bridge design, the BTS7960B allows bidirectional control of motors, enabling forward, backward, braking, and speed regulation with PWM (Pulse Width Modulation) signals. Its thermal protection, overcurrent protection, and built-in diodes ensure safety and reliability, even under demanding conditions. This motor driver module is ideal for hobbyists, engineers, and professionals who need powerful motor control with stable performance.

Key Features of BTS7960B 43A H-Bridge Motor Driver

• High Current Handling Capacity
  Supports up to 43A continuous current and 100A peak current, making it perfect for high-power DC motors.

• Dual H-Bridge Design
  Provides bidirectional motor control with smooth transitions and full braking functionality.

• PWM Speed Control
  Allows precise speed adjustment of motors using PWM signals from Arduino, Raspberry Pi, or other microcontrollers.

• Thermal & Overcurrent Protection
  Built-in safety features prevent overheating, overcurrent, and voltage spikes, protecting both motor and driver.

• Logic-Level Control
  Operates at 5V logic signals, compatible with most microcontrollers and development boards.

• High Efficiency & Reliability
  Designed with low on-resistance MOSFETs, ensuring minimal heat generation and maximum power efficiency.

• Robust Construction
  High-quality PCB, heavy-duty terminals, and solid soldering for long-lasting durability under heavy loads.

Technical Specifications – BTS7960B 43A H-Bridge Motor Driver

• Model: BTS7960B H-Bridge Motor Driver Module

• Motor Voltage Range: 5V to 27V DC

• Continuous Current: 43A

• Peak Current: 100A

• Logic Voltage: 5V

• PWM Frequency: Up to 25kHz

• Inputs: PWM+, PWM-, ENA, ENB for control

• Motor Output: OUT1, OUT2

• Protection Features: Overcurrent, over-temperature, short-circuit, and undervoltage protection

• Dimensions: Approx. 79 × 54 × 27 mm (may vary by manufacturer)

• Operating Temperature: –20°C to +85°C

Note: Always check your motor specifications and driver ratings to ensure safe operation.

Applications of BTS7960B 43A H-Bridge Motor Driver

The BTS7960B motor driver is widely used across robotics, automation, and heavy-duty motor control systems. Its high-current capability and precise PWM control make it versatile for multiple applications:

• Robotics Projects
  Ideal for driving robotic arms, wheeled robots, and autonomous vehicles with smooth bidirectional motion.

• Electric Vehicles & Go-Karts
  Supports high-current DC motors used in electric scooters, go-karts, and small electric vehicles.

• CNC Machines & Automation
  Provides precise motor control for linear actuators, conveyor belts, and automation platforms.

• Industrial Applications
  Used in heavy-duty machinery, industrial automation, and motion control systems requiring high-power motor operation.

• DIY & Hobby Projects
  Perfect for makers and hobbyists building motorized projects, automated systems, or RC vehicles.

• Stepper Motor & High-Torque DC Motor Control
  Can manage stepper motors or large brushed DC motors, enabling accurate positioning and powerful motion.

Why Choose BTS7960B 43A H-Bridge Motor Driver?

The BTS7960B 43A H-Bridge Motor Driver stands out for its high-current handling, robust protection features, and PWM speed control capabilities. Its dual H-Bridge design provides full bidirectional control and braking, making it a reliable solution for both hobbyist and industrial-grade motor applications. Whether you are designing a robotic system, an automated conveyor, or a high-power vehicle, this motor driver ensures smooth, efficient, and precise motor operation every time.

Upgrade your motor control projects with the BTS7960B 43A H-Bridge Motor Driver and experience reliable, high-performance motor operation for demanding applications.

Package Includes:

1 x BTS7960B 43A H-Bridge Motor Driver

FAQ

1. Where can we buy this BTS7960B 43A H-Bridge Motor Driver?

This product is available online at https://aiiottech.in/product/bts7960b-43a-h-bridge-motor-driver/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this BTS7960B 43A H-Bridge Motor Driver after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: BTS7960B 43A H-Bridge Motor Driver
