CD4012 Dual 4-Input NAND Gate IC (DIP-14 Package)

CD4012 Dual 4-Input NAND Gate IC is a versatile CMOS digital logic integrated circuit designed for implementing complex logical functions with high noise immunity and low power consumption. Featuring two independent 4-input NAND gates in a single package, the CD4012 IC is ideal for digital control systems, logic processing, signal gating, and timing applications.

Manufactured using CMOS (Complementary Metal-Oxide Semiconductor) technology, the CD4012 provides extremely low static power dissipation and a wide operating voltage range, making it suitable for both battery-powered devices and industrial electronics. Its robust electrical characteristics and standardized pin configuration allow easy integration into new designs as well as replacement in existing systems.

Key Features of CD4012 Dual 4-Input NAND Gate IC

• Dual 4-Input NAND Gates
  Integrates two independent 4-input NAND logic gates in a single IC, enabling compact circuit design.

• Wide Operating Voltage Range
  Supports supply voltages typically from 3V to 15V, providing flexibility for various logic level requirements.

• Low Power Consumption
  CMOS technology ensures ultra-low static power dissipation, ideal for energy-efficient and battery-operated applications.

• High Noise Immunity
  Offers excellent noise margins, ensuring reliable operation in electrically noisy environments.

• High Input Impedance
  Minimizes loading effects and allows easy interfacing with other CMOS and TTL logic circuits.

• Stable and Reliable Performance
  Designed for consistent switching behavior across a wide temperature and voltage range.

• Industry-Standard Package
  Available in DIP-14 and SOIC-14 packages, compatible with breadboards, PCBs, and automated assembly processes.

Technical Specifications – CD4012 IC

• IC Type: Dual 4-Input NAND Gate

• Logic Family: CMOS 4000 Series

• Model Number: CD4012

• Number of Gates: 2

• Inputs per Gate: 4

• Supply Voltage (VDD): 3V to 15V (typical)

• Logic Function: NAND

• Output Drive Capability: CMOS compatible

• Propagation Delay: Depends on supply voltage and load

• Input Impedance: High

• Operating Temperature Range: –40°C to +85°C (industrial grade)

• Package Type: DIP-14 / SOIC-14

• Mounting Type: Through-hole / Surface mount

Note: Electrical characteristics may vary slightly depending on manufacturer and operating conditions.

Applications of CD4012 Dual 4-Input NAND Gate IC

The CD4012 IC is widely used in digital electronics due to its flexibility, low power operation, and reliable logic performance. Common applications include:

• Digital Logic Circuits
  Used to implement combinational logic, logic gating, and Boolean expressions in digital systems.

• Control and Automation Systems
  Ideal for control logic in industrial automation, relay control, and sequencing circuits.

• Timing and Clock Circuits
  Suitable for pulse shaping, timing generation, and logic control in clock-based systems.

• Signal Gating and Switching
  Enables conditional signal routing and control in communication and data processing circuits.

• Educational and Training Kits
  Frequently used in electronics labs and academic projects for learning digital logic design.

• Consumer Electronics
  Applied in calculators, remote controls, toys, and other low-power digital devices.

• Embedded Systems
  Supports logic expansion and signal conditioning in microcontroller-based designs.

Why Choose the CD4012 NAND Gate IC?

The CD4012 Dual 4-Input NAND Gate IC offers a perfect balance of performance, power efficiency, and design flexibility. With its wide voltage compatibility and low power requirements, it can operate seamlessly in both modern low-voltage systems and legacy designs. The ability to combine multiple inputs into a single NAND function reduces component count, saves board space, and simplifies circuit design.

Additionally, the CD4012’s high noise immunity and stable CMOS operation make it a dependable choice for mission-critical and long-term applications. Whether you are developing a professional electronic product, repairing existing equipment, or experimenting with digital logic circuits, this IC delivers consistent and reliable results.

Upgrade your digital logic design with the CD4012 Dual 4-Input NAND Gate IC and achieve efficient, compact, and reliable logic control across a wide range of electronic applications.

Package Includes:

1 x CD4012 Dual 4-Input NAND Gate IC (DIP-14 Package)

FAQ

1. Where can we buy this CD4012 Dual 4-Input NAND Gate IC?

This product is available online https://aiiottech.in/product/cd4012-dual-4-input-nand-gate-ic/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this CD4012 Dual 4-Input NAND Gate IC after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: CD4012 IC – Dual 4 Input NAND Gate IC Practical Demo with Truth Table
