ESP32-CAM Development Board with WiFi, Bluetooth Module and OV2640 Camera – Best for AI applications

The ESP32-CAM Development Board with OV2640 Camera Module 2MP For Face Recognition has a very competitive small-size camera module that can operate independently as a minimum system with a footprint of only 40 x 27 mm; a deep sleep current of up to 6mA and is widely used in various IoT applications.

It is suitable for home smart devices, industrial wireless control, wireless monitoring, and other IoT applications.

This module adopts a DIP package and can be directly inserted into the backplane to realize rapid production of products, providing customers with high-reliability connection mode, which is convenient for application in various IoT hardware terminals.

ESP integrates WiFi, traditional Bluetooth, and BLE Beacon, with 2 high-performance 32-bit LX6 CPUs, 7-stage pipeline architecture. It has the main frequency adjustment range of 80MHz to 240MHz, on-chip sensor, Hall sensor, temperature sensor, etc.

Key Features of ESP32-CAM Development Board:

• The smallest 802.11b/g/n Wi-Fi BT SoC module.
• Low power 32-bit CPU, can also serve the application processor.
• Up to 160MHz clock speed, summary computing power up to 600 DMIPS.
• Built-in 520 KB SRAM, external 4MPSRAM.
• Supports UART/SPI/I2C/PWM/ADC/DAC.
• Support OV2640 and OV7670 cameras, built-in flash lamp.
• Support image WiFI upload.
• Supports TF card.
• Supports multiple sleep modes.
• Embedded Lwip and FreeRTOS.
• Supports STA/AP/STA AP operation mode.
• Support Smart Config/AirKiss technology.
• Support for serial port local and remote firmware upgrades (FOTA).

Specifications of ESP32-CAM Development Board:

1. Wireless Module: ESP32-S WiFi 802.11 b/g/n Bluetooth 4.2 LE module with PCB antenna, u.FL connector, 32Mbit SPI flash, 4MBit PSRAM.
2. External Storage: micro SD card slot up to 4GB.
3. Camera
   • FPC connector.
   • Support for OV2640 (sold with a board) or OV7670 cameras.
   • Image Format: JPEG( OV2640 support only ), BMP, grayscale.
   • LED flashlight.
4. Expansion: 16x through-holes with UART, SPI, I2C, PWM.
5. Misc: Reset button.
6. Power Supply: 5V via pin header.
7. Power Consumption.
   1. Flash LED off: 180mA @ 5V.
   2. Flash LED on to maximum brightness: 310mA @ 5V.
   3. Deep-sleep: 6mA @ 5V min.
   4. Modem-sleep: 20mA @ 5V min.
   5. Light-sleep: 6.7mA @ 5V min.
8. Dimensions (ESP32): 40 x 27 x 12 (LxWxH) mm.
9. Temperature Range: Operating: -20 ℃ ~ 85 ℃; storage: -40 ℃ ~ 90 ℃ @ < 90%RH.

Applications of ESP32-CAM Development Board:

The ESP32-CAM Development Board, equipped with WiFi, Bluetooth, and an OV2640 camera, finds extensive applications across various domains due to its versatility and capabilities.

1. Surveillance Systems: Utilized for security purposes, the ESP32-CAM enables real-time monitoring of spaces through live video streaming. Its compact size makes it ideal for discreet surveillance setups.
2. IoT Projects: Integrated with WiFi and Bluetooth, the board facilitates seamless connectivity with other IoT devices, enabling remote monitoring and control of home appliances, environmental sensors, and more.
3. Home Automation: Enable remote control of home devices like lights, thermostats, and door locks via smartphone applications or voice commands. The camera feature adds an extra layer of security by providing visual verification.
4. Smart Agriculture: Monitor crops, soil conditions, and livestock remotely, allowing farmers to make informed decisions regarding irrigation, fertilization, and pest control.
5. DIY Projects: Hobbyists and enthusiasts can explore endless possibilities, from creating motion-activated cameras to building interactive art installations and pet monitoring systems.
6. Education: Ideal for STEM education, the ESP32-CAM offers hands-on learning opportunities in electronics, programming, and IoT concepts, fostering creativity and innovation among students.
7. Industrial Automation: Employed in industrial environments for quality control, remote equipment monitoring, and surveillance of sensitive areas.

Package Includes :

1 x ESP32 CAM WiFi Module.

1 x OV2640 Camera Module 2MP.

FAQ

1. who will use this ESP32-CAM Development Board?

Developers, hobbyists, educators, and businesses seeking versatile solutions for IoT, surveillance, automation, and educational projects will benefit from this board

2. what is the use of this ESP32-CAM Development Board?

The ESP32-CAM Development Board integrates WiFi, Bluetooth, and a camera, ideal for IoT, surveillance, home automation, and educational projects

3. Where can we buy this ESP32-CAM Development Board?

This product is available online at https://aiiottech.in/product/esp32-cam-development-board/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

4. When can I get this ESP32-CAM Development Board?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 2-3 working days.

5. How this ESP32-CAM Development Board is better than other products?

Compact design, integrated WiFi, Bluetooth, and OV2640 camera offer versatile functionality, making it superior for IoT, surveillance, and DIY projects.
