CD4001 Quad 2 Input NOR Gate IC (DIP-14 Package)

CD4001 Quad 2 Input NOR Gate IC is a versatile and widely used CMOS logic integrated circuit designed for digital electronics, embedded systems, and educational applications. Featuring four independent 2-input NOR gates on a single chip, the CD4001 provides a compact, low-power, and highly reliable solution for implementing fundamental logic operations.

NOR gates are considered universal logic gates, meaning any digital logic function can be constructed using only NOR gates. This makes the CD4001 IC an essential component for logic design, circuit development, and experimentation. With its wide operating voltage range, excellent noise immunity, and low static power consumption, the CD4001 is suitable for both battery-powered and industrial electronic systems.

Manufactured using CMOS (Complementary Metal-Oxide-Semiconductor) technology, the CD4001 offers high input impedance and minimal power dissipation, ensuring stable and efficient performance across a wide range of operating conditions. It is commonly supplied in a 14-pin DIP package, making it easy to integrate into breadboards, PCBs, and soldered assemblies.

Key Features of CD4001 Quad 2-Input NOR Gate IC

• Four Independent 2-Input NOR Gates
  Integrates four logic NOR gates in a single IC for compact and efficient circuit design.

• Universal Logic Gate Functionality
  NOR gates can be used to implement any basic or complex digital logic function.

• Wide Operating Voltage Range
  Operates reliably from 3 V to 15 V, suitable for both low-voltage and standard logic systems.

• Low Power Consumption
  CMOS design ensures extremely low static power dissipation, ideal for energy-efficient applications.

• High Noise Immunity
  Excellent resistance to electrical noise, ensuring reliable operation in noisy environments.

• High Input Impedance
  Reduces loading effects and allows easy interfacing with other logic families.

• Breadboard & PCB Friendly
  Available in standard DIP-14 package for easy prototyping and installation.

Technical Specifications – CD4001 IC

• IC Type: Quad 2-Input NOR Gate

• Logic Family: CMOS 4000 Series

• Model Number: CD4001

• Number of Gates: 4

• Inputs per Gate: 2

• Supply Voltage (VDD): 3 V to 15 V

• Logic Level: CMOS

• Output Type: Push-Pull

• Operating Temperature Range: –55°C to +125°C

• Propagation Delay: Typically 60 ns (at 10 V)

• Input Capacitance: Low (CMOS standard)

• Package Type: DIP-14 / SOIC-14 (varies by variant)

• Mounting Type: Through-Hole / Surface Mount

Note: Electrical characteristics may vary slightly depending on manufacturer.

Applications of CD4001 Quad 2-Input NOR Gate IC

The CD4001 NOR gate IC is widely used in a variety of digital and mixed-signal applications due to its flexibility, low power consumption, and reliability:

• Digital Logic Circuits
  Used to implement combinational and sequential logic functions such as latches, flip-flops, and oscillators.

• Embedded Systems & Microcontroller Interfacing
  Ideal for signal conditioning, logic inversion, and decision-making circuits.

• Timing & Oscillator Circuits
  Frequently used in RC oscillator and pulse-generation circuits.

• Control & Automation Systems
  Suitable for industrial control panels, alarm systems, and logic controllers.

• Educational & Training Projects
  Commonly used in electronics laboratories, academic projects, and logic gate demonstrations.

• Consumer Electronics
  Found in calculators, remote controls, and low-power digital devices.

• DIY Electronics & Prototyping
  Preferred by hobbyists for breadboard experiments and custom logic designs.

Why Choose the CD4001 Quad NOR Gate IC?

The CD4001 IC stands out as a reliable and cost-effective solution for digital logic applications. Its universal gate capability, wide voltage operation, and low power consumption make it suitable for both beginners and professionals. Whether you are designing a simple logic circuit or developing a complex digital system, the CD4001 delivers consistent performance and long-term reliability.

Add the CD4001 Quad 2-Input NOR Gate IC to your electronics toolkit and simplify your digital circuit designs with proven CMOS logic technology.

Package Includes:

1 x CD4001 Quad 2 Input NOR Gate IC

FAQ

1. Where can we buy this CD4001 Quad 2 Input NOR Gate IC?

This product is available online https://aiiottech.in/product/cd4001-quad-2-input-nor-gate-ic/ and also available at our store in Pudupakkam/Kelambakkam, Chennai-603103

2. When can I get this CD4001 Quad 2 Input NOR Gate IC after placing the order?

RGRJ AIIoT TECHNOLOGIES will immediately ship and deliver the product within 1-3 working days.

Video Link: CD4001 Quad 2-Input NOR Gate
